User's Manual
MODEL 10 PLUS
MODEL 8 PLUS
SWITCHERS

Advertisement

loading
Need help?

Need help?

Do you have a question about the 10 Plus and is the answer not in the manual?

Questions and answers

Related Manuals for Extron electronics 10 Plus

Summary of Contents for Extron electronics 10 Plus

  • Page 1 User's Manual MODEL 10 PLUS MODEL 8 PLUS SWITCHERS...

  • Page 3: Table Of Contents

    Contents Model 8/10 PLUS Introduction and Specifications ..... Chapter 1 About this Manual ..............1-1 Facts and Features ............... 1-1 Description of Features ..........1-2 Specifications ............... 1-3 Model 8/10 PLUS Operation and Configuration ....Chapter 2 Operation and Front Panel Descriptions ....... 2-1 Rear Panel Descriptions ............
  • Page 4 _ A Note, a Hint, or a Tip that may be helpful. __ Possible Electrostatic Discharge (ESD) damage could result from touching electronic components. __ Additional information may be referenced in another section, or in another document. Extron • Model 8 PLUS & Model 10 PLUS Switchers • User’s Manual...
  • Page 5 Extron’s Model 8/10 PLUS Switchers User’s Manual Chapter One Model 8/10 PLUS Switcher Introduction Features Specifications Extron • Model 8 PLUS & Model 10 PLUS Switchers • User’s Manual...

  • Page 6: Model 8/10 Plus Introduction And Specifications

    Available Models and Part Numbers are: Model 8 PLUS Switcher – 60-094-01 Model 10 PLUS Switcher – 60-095-01 The Model 8 PLUS front and back panels are shown below. Page 1-1 Extron • Model 8 PLUS & Model 10 PLUS Switchers • User’s Manual...

  • Page 7: Description Of Features

    Rear Panel LED Indicators – Rear panel LEDs indicate which input is selected and which outputs are active. The Model 10 PLUS front and back panels are shown below. Extron • Model 8 PLUS & Model 10 PLUS Switchers • User’s Manual Page 1-2...

  • Page 8: Specifications

    Sync Input Impedance ..510 Ohms Gain ..None Connectors ..Input Type ..BNC (Female) ..Output Type ..BNC (Female) ..4 Pin Mini-DIN (S -Video) Page 1-3 Extron • Model 8 PLUS & Model 10 PLUS Switchers • User’s Manual...
  • Page 9 Extron’s Model 8/10 PLUS Switchers User’s Manual Chapter Two Model 8/10 PLUS Switcher Operation and Installation Switcher Operation Front Panel Rear Panel Switcher Installation Guide Extron • Model 8 PLUS & Model 10 PLUS Switchers • User’s Manual...

  • Page 10: Model 8/10 Plus Operation And Configuration

    * – (A) thru (K) refer to the drawing and descriptions on the facing page. Model 10 PLUS Front Panel Page 2-1 Extron • Model 8 PLUS & Model 10 PLUS Switchers • User’s Manual...

  • Page 11: Rear Panel Descriptions

    Remote connector - See page A-1 for a detailed description. * – Letters next to the descriptions above are keyed to the circled letters in the drawing below. Extron • Model 8 PLUS & Model 10 PLUS Switchers • User’s Manual Page 2-2...

  • Page 12: Installation Guide

    G = Green G = Green Y Video Video B = Blue B = Blue L (Left) Audio L (Left) Audio Sync Unused C Video Unused Page 2-3 Extron • Model 8 PLUS & Model 10 PLUS Switchers • User’s Manual...
  • Page 13 Players and VCRs will most likely require RCA to BNC adapters. An adapter of this type can generally be purchased at your local electronics store. Extron • Model 8 PLUS & Model 10 PLUS Switchers • User’s Manual Page 2-4...

  • Page 14: Output Select Dip Switch Setting

    (slide) the switch to the desired position (RGBS or VIDEO). See examples on facing page. Page 2-5 Extron • Model 8 PLUS & Model 10 PLUS Switchers • User’s Manual...

  • Page 15: Example Select Dip Switch Settings

    Extron • Model 8 PLUS & Model 10 PLUS Switchers • User’s Manual Page 2-6...

  • Page 16: Changing The Baud Rate

    E = 19200 baud 7 = 38400 baud F = 38400 baud _ Adjust SW3 to set the RS-232 Baud Rate and Protocol. SW3 Rotary Switch Page 2-7 Extron • Model 8 PLUS & Model 10 PLUS Switchers • User’s Manual...

  • Page 17: Model 8/10 Plus Switcher Connection To Computer

    10 is labeled A on the switch. (10 11 = B, 12 = C, 13 = D, 14 = E and 15 = F) Extron • Model 8 PLUS & Model 10 PLUS Switchers • User’s Manual Page 2-8...
  • Page 18 Notes: Extron • Model 8 PLUS & Model 10 PLUS Switchers • User’s Manual...

  • Page 19: Model 8/10 Plus Rs-232 Control

    Extron’s Model 8/10 PLUS Switchers User’s Manual Chapter Three Model 8/10 PLUS RS-232 Control Host/Switcher Communications Command/Response Table Control Software Extron • Model 8 PLUS & Model 10 PLUS Switchers • User’s Manual...

  • Page 20: Software

    The Command string in the left hand column of the table is defined in the right hand column. The Command string is shown as ASCII characters, an ASCII to HEX conversion table is provided. Page 3-1 Extron • Model 8 PLUS & Model 10 PLUS Switchers • User’s Manual...

  • Page 21: Command/Response Table

    V2 = Input Channel 2 T4 = S-Video Format M8 = 8 Inputs (Model 8 PLUS) Q1.23 = Software Version 1.23 N60-095-01 Part Number = 60-095-01 Extron • Model 8 PLUS & Model 10 PLUS Switchers • User’s Manual Page 3-2...

  • Page 22: Software

    Comm Port that is connected to the Model 8/10 Switcher RS-232 port. The Extron UNIVersal SW Control Program window displays input selection (see picture below). Page 3-3 Extron • Model 8 PLUS & Model 10 PLUS Switchers • User’s Manual...
  • Page 23 Model 8/10 PLUS RS-232 Control Model 10 PLUS Switcher w/PC RS-232 Control Extron • Model 8 PLUS & Model 10 PLUS Switchers • User’s Manual Page 3-4...
  • Page 24 Notes: Extron • Model 8 PLUS & Model 10 PLUS Switchers • User’s Manual...

  • Page 25: Configuring Features And Options

    Extron’s Model 8/10 PLUS Switchers User’s Manual Appendix A Configuring Features and Options Remote Connector KP-10 Remote Control IR-10 Remote Control Rack Mounting Extron • Model 8 PLUS & Model 10 PLUS Switchers • User’s Manual...

  • Page 26: Manual Remote Connector

    REQUIREMENT OF LAMP 330 Ohm Using a Relay +5V (PIN 13) 1N916 & External Power TALLY PIN 330 Ohm TALLY PIN EXTERNAL POWER TALLY PIN Page A-1 Extron • Model 8 PLUS & Model 10 PLUS Switchers • User’s Manual...

  • Page 27: Hard Wired Remote Control

    The E part number for the KP-10 is 60-111-01. XTRON Extron • Model 8 PLUS & Model 10 PLUS Switchers • User’s Manual Page A-2...

  • Page 28: Ir-10 Infrared Remote Control

    IR-10 hand held remote controller (limited by a 6' cable). Power the switcher ON. The E part number for the IR-10 is 70-036-01. XTRON Model 10 PLUS Switcher Page A-3 Extron • Model 8 PLUS & Model 10 PLUS Switchers • User’s Manual...
  • Page 29 Installing the Model 8/10 PLUS Switcher on the Shelf The 2U Universal Rack Shelf is designed to enable the Model 8 PLUS or Model 10 PLUS Switcher to set on the shelf with the switcher's four feet extending through four holes. It is not necessary to attach the switcher to the shelf with screws.

  • Page 30: Accessories/Part Numbers

    BNC-4-200’HR (200 feet/60.0 meters) ....... 26-210-09 BNC-4-250’HR (250 feet/75.0 meters) ....... 26-210-54 BNC-4-300’HR (300 feet/90.0 meters) ....... 26-210-53 BNC-4 Mini-HR Bulk (300’/90m up to 5000’/1500m) .. 22-073-01 Page A-5 Extron • Model 8 PLUS & Model 10 PLUS Switchers • User’s Manual...

This manual is also suitable for:

8 plus
