Service menu continued ...
Main item Sub-item
1 RECIPE
2 RECIPE
2.03
3 RECIPE
RECIPE SETTINGS
4 RECIPE
ETC.
Sub Item
BREWER VALVE 1
DELAY TIME (DV1)
BREWER VALVE 1
(DV1)
RINSE 1 DELAY
TIME
RINSE 1
COFFEE DELAY
COFFEE
START 1 BREWER
PAUSE 1 BREWER
(FILLINg)
UNIT 1
START 2 BREWER
PAUSE 2 BREWER
(ExTRACTION)
START 3 BREWER
PAUSE 3 BREWER
(DRYINg)
START 4 BREWER
PAUSE 4 BREWER
(POUR OUT)
64
OptiFresh (Bean) Touch
Range Set Description
0,0-30,0 s Brewer valve (DV1) delay time
Dispensing volume brewer valve
0-100 ml
(DV1)
0,0-20,0 s Delay time rinse Water (DV1)
Dispensing volume rinsing water
0-15 ml
automatically deducted from DV1
0,0-30,0 s 0,5 s Coffee (grinder) delay time
0,00-5,00 s Coffee (grinder) dispensing time
Time the brewer motor runs the
0,0-30,0 s 1,0 s
piston leaves the start position.
Pause time the piston stay in
position to allow the brewer
0,0-30,0 s 6,0 s
chamber (top) is filled with coffee
grounds and hot water.
Time the brewer motor runs the
piston in the highest position. The
air above the piston allow to get a
perfect mix of the coffee grounds
with the water.
0,0-30,0 s 2,4 s
If foam bubbles out over the brewer
chamber when the piston moves
up you can decrease the set value.
The decreased time is automatically
deducted from Start 1 brewer.
Pause time the piston stay in the
highest position to allow more
0,0-30,0 s 2,5 s
contact time between the coffee
grounds and water.
Time the brewer motor runs the
0,0-30,0 s 3,0 s piston down just before to the pour
out opening
Pause time the piston pauses just
before the outlet to let de vacuum
0,0-30,0 s 1,5 s
pull the liquid coffee down and dry
the coffee residue
Time the brewer motor runs the
0,0-30,0 s 1,9 s
piston down to the pour out opening
Pause time the piston pauses in the
0,0-30,0 s 3,5 s open position to empty the brewer
cylinder.
