OptiFresh (Bean) Touch

3. PRINCIPlES OF OPERATION

3

2
Item Description
1. Coffee waste bin
2. Freshbrew group
3. gear motor brewer
Coffee bean canister (OF Bean)
4.
Fresh brew canister (OF)
Coffee grinder (OF Bean)
5.
gear motor fresh brew canister (OF)
6. Dispensing valve
7. Boiler
8. Instant canisters
2017/09 Rev. 0.0
4 5
10
1
18
6 7 8
11
12
17
Item Description
9. gear motor instant canister
10. Inlet valve
11. Evaporation extractor ring
12. Mixer housing
13. Mixer motor
14. Mixer impellor
15. Extraction tray
16. Ventilator
17. Hot water outlet
18. Coffee outlet / Drink outlet (instant)
27
9
15
14
13
EN
16
