10. FAULT ANALYSIS
WARNING
● When carrying out repairs and cleaning the device, the plug should always be removed from the
wall socket before the device is opened.
Preface
Before searching for the defect, check that all parts are in their correct position. To do this, remove
the device's rear plate and check that all printed circuit boards, connectors, wire beams and pipes are
mounted correctly.
After carrying out a general parts inspection, use section 10.4 Troubleshooting analysis to verify the
probable cause of the problem.
#) If the column solution advises replacement of the part concerned, there is always the possibility
that the defect may be caused by another problem. The functioning of the device should therefore be
thoroughly tested to make sure that the defect does not reappear.
10.1 Read log
During use, the last 20 error messages displayed
are registered and saved.
To read these error messages, activate the menu item
2.08 LOG BESTAND LEZEN
Read log (menu 2.8) in the service menu. The first error
displayed is the most recent error message.
• The 1st line shows the error code, the date time at
which the error occurred.
• The 2nd line shows the Error numer and description
used in the fault analysis table (see chapter 10.4).
10.2 Clear log
Use the Clear log function (service menu 2.9) to clear the
log.
2017/09 Rev. 0.0
2.08 LOG LESEN
01: E25 23-01-17 15:05 E25
FLOWMETER FOUT

02:

03:
Index
number
2.08 READ LOG FILE
01: E25 23-01-17 15:05
E25 FLOWMETER ERROR
02:
03:
Error code + description
OK
117
2.08 LECTURE FICHIER HISTORIQUE
Time
Date
OK
