OptiFresh (Bean) Touch
3.4 Fresh brew group
The fresh brew group consists of a fresh brew unit [ 4 ] and an drive unit [ 5 ]. The drive unit carries
a DC gear motor with drives the fresh brew unit (Pre)grinded coffee [ 3 ] and hot water [ 4.1 ] are
dispensed onto the permanent filter [ 4.4 ] and are drawn trough the filter by a piston [ 4.5 ] (vacuum).
After the coffee is dispensed to the cup [ 4.6 ] the coffee residue is wiped away by the wiper [ 4.3 ] and
drops into the waste bin. Next sections explain how the unit operates.
Major components
1. Bean canister / Fresh brew canister
2. Coffee grinder / canister gear motor
3. Coffee guide
4. Fresh brew unit
4.1 Water supply
4.2 Brewer chamber
4.3 Wiper
4.4 Permanent filter
4.5 Piston
4.6 Coffee outlet
5. Drive unit
1
2
3
2017/09 Rev. 0.0
4.1
Technical data
1
4.2
Content 2,2 kg / 1,8 kg
See 3.6 Coffee grinder
4.3
2
4.4
max. 240 ml with 16-20 gram coffee
3
4
4.5
M
37 µm
5
See 3.5 Drive unit
1
2
3
M
(art.no. 03488)
4.1
4.2
4.3
4.4
4
4.5
5
33
Material
PC / PE
EN
st.st. / PE
PSU
PSU
4.6
st.st.
Teflon
4.6
