8. COMPONENT ACCESSIBIlITY
Fresh brew canister
Bean canister
Instant canisters
Display
Circuit board
SD / USB slot
Brewer
Co ee outlet
Drip tray full sensor
OptiFresh Touch
OptiFresh Bean Touch
108
OptiFresh (Bean) Touch
Dispensing valves
Ingredient motors
Mixer
Ventilator
Waste bin switch
Main switch
Waste bin
2017/09 Rev. 0.0
