Using the Module Profile Tool to import the 2085sc-OF8 AOP into CCW
NOTE
software is necessary only if you are using a CCW version earlier than
11.00.00. For information on manually importing an AOP file, see
Appendix A. For Version 11.00.00 and later, the module is already
available as a selection from the CCW Expansion Modules drop-down
menu:
To add the module to your project, and see its configuration parameters on the

CCW configuration tab:

1. From your CCW project, load the module AOP to a first Available slot
from the Expansion Modules drop-down list.
2. Once the module AOP is loaded, to view the associated variables, click
the Module Catalog Name option.
Chapter 3: Configuring the 2085sc-OF8 Using CCW
User's Manual Pub. 0300308-02 Rev. A
3-5
