3-24 Chapter 3: Configuring the 2085sc-OF8 Using CCW
Fault Code
0×F29z
6
Fault Extended Fault Code
0×410-417
0×F2Bz
7
0×420-427
z indicates the slot number of the expansion I/O. If z=0, then the slot number cannot be identified
6
z indicates the slot number of the expansion I/O. If z=0, then the slot number cannot be identified
7
User's Manual Pub. 0300308-02 Rev. A
• All Outputs are turned off if a hardware fault is detected. If the hardware
fault clears, the outputs resume the previous setting.
• All outputs are turned off when Program Mode is detected. Outputs
resume normal operation when Run Mode is detected.
3.5.17 Module Specific Hardware Errors
A Micro850 or 870 PLC can generate a series of 0×F2xy error codes specific to
an Expansion I/O module. The Fault code is 0×F29z, where z indicates the slot
number of the expansion I/O. If z=0, then the slot number cannot be identified.
Extended Fault Code Error Description
0×301
0×302
0×303
0×304
0×305
3.5.18 Module Specific Configuration Errors
If you set invalid configuration values in the PLC, the CCW will generate a
configuration fault. The connection status will be defaulted and disconnected.
MCU Watchdog reset
MCU board power brownout
Output driver over temperature
Unused
DAC communications error
Error Description
Invalid Range
The Range setting is not within the valid
selectable range. See Configuration Table for
possible values.
Invalid Data Format
The Data Format setting is not within the
valid selectable range. See Configuration
Table for possible values.
