3-20 Chapter 3: Configuring the 2085sc-OF8 Using CCW
Bit
0 Name Description
3:1 Disable Set to 1 to disable channel.
0 = 4-20 mA
1 = 0-20 mA
6:4 Range 2 = ±10 V
3 = 0-10 V
4 = 0-5 V
0 = EU ×1
1 = Raw/Proportional
7 Format
2 = Scaled for PID
3 = Percent of range
High Clamp Enable
8 HCE The High Clamp configuration value is used to clamp the maximum output.
The High Clamp configuration value is ignored when this bit is cleared.
Low Clamp Enable
9 LCE The Low Clamp configuration value is used to clamp the minimum output.
The Low Clamp configuration value is ignored when this bit is cleared.
High Clamp Alarm Enable
This bit is only valid when HCE bit is set. It is ignored when HCE is cleared.
When HCE and HCA are both set, the Over Range Alarm status bit is only set
when the user Output is greater than or equal to the High Clamp value.
10 HCA
When HCE is set and HCA is cleared, the Over Range Alarm is determined by
the High Range value indicated in the Output Range Table. In this case the
Over Range alarm may not be set if the High Clamp value is less than the High
Range value since the final output cannot reach that value due to clamping.
Low Clamp Alarm Enable
This bit is only valid when LCE bit is set. It is ignored when LCE is cleared.
When LCE and LCA are both set, the Under Range Alarm status bit is only set
when the Output is less than or equal to the Low Clamp value
11 LCA
When LCE is set and LCA is cleared, the Under Range Alarm is determined
by the Low Range value indicated in the Output Range Table. In this case the
Under Range alarm may not be set if the Low Clamp value is less than the
Low Range value since the final output cannot reach that value due to
clamping.
User's Manual Pub. 0300308-02 Rev. A

3.5.12 Configuration Bit Definition
