Chapter 3: Configuring the 2085-IT8-SC/IT-16-SC Using CCW
Using the Module Profile Tool to import the AOPs into CCW software is
NOTE
necessary only if you are using a CCW version earlier than 11.00.00. For
information on manually importing an AOP file, see Appendix A. For
Version 11.00.00 and later, the module is already available as a selection
from the CCW Expansion Modules drop-down menu:
To add the module to your project, and see its configuration parameters on the

CCW configuration tab:

1. From your CCW project, load the module AOP to a first Available slot
from the Expansion Modules drop-down list (2085-IT8-SC is used as the
example here):
2. Once the module AOP is loaded, to view the associated variables, click
the Module Catalog Name option.
User's Manual Pub. 0300322-01 Rev. B
3-7
