User Scaling/Data Format And Range - Spectrum Controls Micro 800 User Manual

Range
0 V ~ 5 V
0 V ~ 10 V
-10 V ~ +10 V

3.5.15 User Scaling/Data Format and Range

The meaning of the Output Word of each channel depends on the Range and
Data Format settings.
The Data Format and Range parameters in the channel configuration bits
determine scaling. There are four pre-defined Data Format settings.
The following table shows the pre-defined scaling values and how they match
with the output Analog Signal.
AnalogOutput = UserValue * M + B
See corresponding M and B values in the table below.
Output Range Condition
High Limit
High Range
4 to 20 mA
Low Range
Low Limit
High Limit
High Range
0 to 20 mA
Low Range
Low Limit
High Limit
High Range
±10 V
Low Range
Low Limit
High Limit
High Range
0 to 5 V
Low Range
Low Limit
High Limit
High Range
0 to 10 V
Low Range
Low Limit
3.5.16 Fault Mode/Program Mode Operation
During operation, the module may detect a hardware fault or that the system has
changed the run mode (run/program).
Chapter 3: Configuring the 2085sc-OF8 Using CCW
Low Limit Low Range
0.0 V 0.0 V
0.0 V 0.0 V
-10.5 V -10.0 V
Analog Signal Raw/Prop
20.40 mA 32767
20.00 mA 31176
4.00 mA -32450
3.92 mA -32768
20.40 mA 32767
20.00 mA 31482
0.00 mA -32768
0.00 mA -32768
10.50 VDC 32767
10.00 VDC 31207
-10.00 VDC -31208
-10.50 VDC -32768
5.25 VDC 32767
5.00 VDC 29646
0.00 VDC -32768
0.00 VDC -32768
10.50 VDC 32767
10.00 VDC 29646
0.00 VDC -32768
0.00 VDC -32768
High Range High Limit
+5.0 V
+10.0 V
+10.0 V
EU PID
20400 16793
20000 16383
4000 0
3920 -82
20400 16711
20000 16383
0 0
0 0
10500 16793
10000 16383
-10000 0
-10500 -410
5500 17202
5000 16383
0 0
0 0
10500 17202
10000 16383
0 0
0 0
