3. Push the DIN rail latch back into the latched position. Use DIN rail end
4. Snap the module into the module bay.
Hazard of damage to equipment.
WARNING
The Spectrum Controls RTB hold down and terminal screws must be
tightened by hand using the guidelines in Step 5. They must not be
tightened using a power tool.
Failure to follow these guidelines may result in damage to your connector.
5.
Panel Mounting
The preferred mounting method is to use two M4 (#8) screws per module. Hole
spacing tolerance is ±0.4 mm (0.016 in.). For mounting dimensions, refer to
Micro830, Micro850, and Micro870 Programmable Controllers User Manual
2080-UM002:
1. Place the module next to the controller against the panel where you are
2. Marking drilling holes through the mounting screw holes and mounting
3. Drill the holes at the markings.
4. Replace the module and mount it. Leave the protective debris strip in
anchors for vibration or shock environments.
Use a slot screwdriver of 0.8 × 2.0 mm and carefully tighten to no more
than 2.2 Lb-in torque (0.25 Nm).
mounting the module.
feet, and then remove the module.
place until you are finished wiring the module, and any other devices.
Chapter 2: Installation and Wiring
User's Manual Pub. 0300308-02 Rev. A
2-7
