Bit
0 Name Description
High Limit Alarm Enable
This bit is only valid when the HCE bit is cleared. It is ignored when HCE is
set.
When HCE is cleared and HLA set, the Over Range status bit is set when the
12 HLA
Output is set to a value greater than or equal to the High Limit value indicated
in the Output Range Table.
When HCE is cleared and HLA cleared, the Over Range Alarm status bit is set
when the Output is set to a value greater than or equal to the High Range value
indicated in the Output Range Table.
Low Limit Alarm Enable
This bit is only valid when the LCE bit is cleared. It is ignored when LCE is
set.
When LCE is cleared and LLA is set, the Under Range Alarm status bit is set
13 LLA
when the Output is set to a value less than or equal to the Low Limit value
indicated in the Output Range Table.
When LCE is cleared and LLA is cleared, the Under Range Alarm status bit is
set when the Output is set to a value less than or equal to the Low Range value
indicated in the Output Range Table.
Alarm Latch Enable
When this bit is set, the Over Range, Under Range and LD Alarm bits will
15:14 ALE
remain set even when the Alarm condition is cleared. The Unlatch Alarm bits
for this channel in the Output Table must be set to clear the alarms.
Chapter 3: Configuring the 2085sc-OF8 Using CCW
High Clamp, Low Clamp Value
The High Clamp value will be ignored if HCE is not set.
•
• The Low Clamp value will be ignored if LCE is not set.
If you set the High or Low Clamp beyond the Limit for the specific
Range/Format setting, the output is internally adjusted to the Limit values. In this
case, the Limit value determines the Over or Under Range Alarm trigger if HCA
or LCA is set respectively (assuming HCE or LCE is set).
