Terminal Block signal descriptions are as follows:
RTB Name
1 V/I OUT0
2 RTN0
3 V/I OUT1
4 RTN1
5 V/I OUT2
6 RTN2
7 V/I OUT3
8 RTN3
9 V/I OUT4
10 RTN4
11 V/I OUT5
12 RTN5
13 V/I OUT6
14 RTN6
15 V/I OUT7
16 RTN7
17 +24V DC
18 COM DC
Chapter 2: Installation and Wiring
Description
Channel 0 voltage or current output
Channel 0 return
Channel 1 voltage or current output
Channel 1 return
Channel 2 voltage or current output
Channel 2 return
Channel 3 voltage or current output
Channel 3 return
Channel 4 voltage or current output
Channel 4 return
Channel 5 voltage or current output
Channel 5 return
Channel 6 voltage or current output
Channel 6 return
Channel 7 voltage or current output
Channel 7 return
24V DC power from field
Field common ground
