1-8
Chapter 1, Module Overview
Blink
Name and Description
Code
Offline
Rapid continuous blinking indicates the
rapid
module is offline and outputs are
disabled.
Run Mode
ON
The LED is solid green.
User's Manual Pub. 0300308-02 Rev. A
GREEN. If the LED remains off, there is an error with the module: it may not
have power, or the module failed to pass the self-test.
Table 1-4 LED Blink Codes for Firmware 1.1
Indicator
State
Off
Solid
Green
Module OK
LED Status
Blinking
Green
1.4.3 2.1 LED Operation
A 2085sc-OF8 module with Version 2.1 firmware uses a single, green OK LED
to show power or module operational status:
•
When startup is completed, and all internal tests have passed, the LED is
solid GREEN. This indicates RUN mode.
•
If the LED remains off, there is an error with the module: it may not have
power or failed to pass the self-test.
•
Any time the system is not in Run mode (and showing no faults), the
LED blinks rapidly, indicating the module is Offline. All inputs and
outputs are disabled in this instance.
The LED identifies different conditions using specific, numeric, blink patterns.
The module blinks a specific number of times, pauses, and then repeats the same
blink pattern indefinitely. Blink codes are shown in the following table.
Table 1-5 LED Blink Codes Table for Firmware 2.1
Description
No power applied to device or the module may have
failed to pass its self-test.
RUN mode. Module has power and passed self-test.
No action is required.
LED blink status:
1. Internal use only.
2. Internal use only.
3. Internal use only.
4. Internal use only.
5. Indicates ADC communication error.
6. Indicates Watchdog reset.
Resolution
Set controller to RUN mode.
This will also be seen during power-on while it is
initializing.
Module is initialized with no hardware fault
detected. Module is in Run mode.
