PLC Interfaces

Parameter
Vendor ID
Product Type
Product Code
Series Rev (1.1)
Series Rev (2.1)
Module Catalog String
Chapter 3: Configuring the 2085sc-OF8 Using CCW
The 2085 platform treats all data on an I/O module as a member of a named
Array of Words.
Module Identity
The following values are stored in the Vendor ID, Product_Type, Product_Code,
Series_Rev, and Mod_Features arrays:

3.5.2 Connection Types and Assembly Sizes

The size of each assembly is listed in the table below. Each word takes 2 bytes.
These values are stored in the Mod_Size array:
Table
Configuration Assembly
Input Assembly
Output Assembly
Hex
OF8
0×3A (58)
58 (Spectrum Controls)
0×0A
10 (Analog)
0×71
(113)
50208 (First release
0×C420
revision is 1.1)
0×C820
51232 (Second release
revision is 2.1)
2085sc-OF8
Size (Words)
32
14
10
User's Manual Pub. 0300308-02 Rev. A
3-13
