Link/Activity LED The two LEDs Link (green) and Activity (yellow), integrated in the RJ45 plug connec-
tors (X30, X32), display the status of the Ethernet connection.
LED "Activity"
LED/state
Link/green
Link/off
Activity/yellow
INFORMATION
•
•

4.10.2 Gateway LED

LEDs H1 and H2 indicate the communication status in gateway operation.
LED H1 Sys-fault (red)
Status
Red
Off
Flashing
INFORMATION
•
•
Manual – DFE32B Fieldbus Interface PROFINET IO
Assembly and Installation Notes
LED "Link"
Meaning
There is an Ethernet connection.
There is no Ethernet connection.
Data is currently being exchanged via Ethernet.
As the firmware of the DFE32B option card requires approximately 10 seconds for
initialization, the status "0" (inverter not ready) is displayed in the 7-segment dis-
®
play of MOVIDRIVE during this time.
The Run LED on the DFE32B option card lights up green.
H1
H2
X24
Status
System error
SBus ok
Bus scan
LED H2 (green) is currently reserved.
X terminal X24 is the RS485 interface for diagnostics via PC and MOVITOOLS
MotionStudio.
Operating display DFE32B option
Only for gateway function
Description
Gateway is not configured or one of the
drives is inactive
Gateway is configured correctly
Bus is being checked by the gateway
