Technical Data; Dfe32B For Movidrive ® B, Movitrac ® B And Uoh11B - SEW-Eurodrive DFE32B PROFINET IO Manual

n
kVA

Technical Data

11
f
DFE32B for MOVIDRIVE® B, MOVITRAC® B and UOH11B
i
P Hz
11 Technical Data
11.1 DFE32B for MOVIDRIVE
126
®
B, MOVITRAC
DFE32B option
Part number
Power consumption
Voltage supply (only in
gateway operation)
Application protocols •
•
•
Port numbers used •
•
Ethernet services •
•
ISO/OSI layer 2
Baud rate
Connection technology
Addressing
Manufacturer ID
(Vendor ID)
Tools for startup •
•
Firmware status of
®
MOVIDRIVE MDX61B
®
B and UOH11B
1821 345 6
P = 3 W
U = DC 24 V (-15%/+20%)
I = DC 200 mA
max
P = 3.4 W
max
PROFINET IO (Ethernet frames with frame identification 8892
trol and parameterize the inverter.
HTTP (Hypertext Transfer Protocol) for diagnostics using a Web browser.
SMLP (Simple Movilink Protocol), protocol used by MOVITOOLS
300 (SMLP)
80 (HTTP)
ARP
ICMP (ping)
Ethernet II
100 MBd in full duplex mode
RJ45
4 byte IP address or MAC-ID (00:0F:69:xx:xx:xx)
010A
hex
®
MOVITOOLS MotionStudio version 5.40 and higher.
DBG60B keypad
Firmware version 824 854 0.17 or later (→ display with P076)
Manual – DFE32B Fieldbus Interface PROFINET IO
) to con-
hex
®
.
