9.7

Serial (RS-485) communication via interface adapter

9.7.1

Engineering via interface adapters (serial)

As your unit supports "Serial" communication, you can use a suitable interface adapter
for engineering.
The interface adapter is additional hardware that you can obtain from
SEW-EURODRIVE. You can use it to connect your engineering PC with the respective
communication option of the unit.
The following table shows you the different types of interface adapters available, and for
which units they are suitable.
Type of interface
adapter (option)
USB11A
(USB to RS-485)
UWS21B
(RS-232 to RS-485)
UWS11A
(RS-232 to RS-485)
for mounting rail
As the majority of PCs come equipped with USB interfaces instead of RS-232 interfaces,
the following section only focuses on the USB11A interface.
9.7.2

Taking the USB11A interface adapter into operation

Overview The USB11A interface adapter uses a COM redirector. This assigns the first free COM
port to the interface adapter.
The following section describes how to connect the USB11A interface adapter and, if
required, install the respective drivers.
Manual – DFE32B Fieldbus Interface PROFINET IO
MOVITOOLS® MotionStudio – Operation
Serial (RS-485) communication via interface adapter
Order no.
08248311
18204562
822689X
Scope of delivery
2 connection cables:
• TAE connection cable
with 2 RJ10 plugs
• USB connection cable
with USB-A plug and
USB-B plug
2 connection cables:
• TAE connection cable
with 2 RJ10 plugs
• Connection cable with 9-
pin D-sub plug
Without
Units
®
• MOVIDRIVE B
®
• MOVITRAC 07A
®
• MOVITRAC B
®
• MOVIFIT MC/FC/SC
®
• MOVIGEAR
• UFx11A fieldbus gateways
• DFx fieldbus gateways
®
• DHx MOVI-PLC controller
• MFx/MQx fieldbus interfaces
®
for MOVIMOT
