2. From the list [1], select "Serial" as the communication type.
3. Press the [Edit] button [3] on the right side of the "Configure communication plugs"
4. It might be necessary to change the preset communication parameters on the tab
Manual – DFE32B Fieldbus Interface PROFINET IO
MOVITOOLS® MotionStudio – Operation
Serial (RS-485) communication via interface adapter
In the example, "Serial" is activated as the communication type for the first commu-
nication channel [2].
window.
This will display the settings for the "serial" communication type.
pages [Basic settings] and [Advanced settings]. Refer to the detailed description of
the communication parameters.
