MOVITOOLS® MotionStudio – Operation
9
Communication SBus (CAN) via interface adapter
9.8.4

Communication parameters for SBus

112
The following table describes the [Basic setting] for the SBus communication channel:
Communication parameters
Baud rate
The following table describes the [Advanced setting] for the SBus communication chan-
nel:
Communication parameters
Parameter telegrams
Multibyte telegrams
Timeout
Retries
Description
Transmission speed with which
the connected PC communicates
with the unit in the network via the
communication channel.
Description
Telegram with a single parameter
Telegram with several parameters Used for transmitting the com-
Waiting time in [ms] that the mas-
ter waits for a response from the
slave after it has sent a request.
Number of request retries after
the timeout is exceeded
Manual – DFE32B Fieldbus Interface PROFINET IO
Note
• Adjustable values (permitted
total cable length):
• 125 kBaud (500 m)
• 250 kBaud (250 m)
• 500 kBaud (100 m)
(default)
• 1 MBaud (25 m)
• All connected units must sup-
port the same baud rate.
Note
Used for transmitting a single
parameter of a unit.
plete parameter set of a unit.
• Default setting:
• 100 ms (parameter tele-
gram)
• 350 ms (multibyte tele-
gram)
• Increase the value if not all
units are detected during a
network scan.
Default setting: 3
