Compact Manual
Drive System for Decentralized Installation
PROFINET IO Interfaces, Field Distributors
Edition 12/2016
23104910/EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MFP Series and is the answer not in the manual?

Questions and answers

Related Manuals for SEW-Eurodrive MFP Series

Summary of Contents for SEW-Eurodrive MFP Series

  • Page 1 *23104910_1216* Drive Technology \ Drive Automation \ System Integration \ Services Compact Manual Drive System for Decentralized Installation PROFINET IO Interfaces, Field Distributors Edition 12/2016 23104910/EN...
  • Page 2 SEW-EURODRIVE—Driving the world...

  • Page 3: Table Of Contents

    Contents Contents General information........................  5 Scope of this documentation................... 5 Structure of the safety notes ................... 6 Safety notes ..........................  7 Preliminary information .................... 7 Operator's duties...................... 7 Target group ........................ 7 Designated use ....................... 8 Functional safety technology .................. 9 Transport......................... 9 Installation/assembly....................... 9 Electrical connection ..................... 10 Protective separation .................... 10 2.10 Startup/operation ...................... 11 Type esignation........................
  • Page 4 Contents Error list for fieldbus interfaces .................. 72 Declaration of conformity ......................   73 Compact Manual – PROFINET IO Interfaces, Field Distributors...

  • Page 5: General Information

    The enclosed CD or DVD contains PDF files of the detailed manual and the oper- ating instructions as well as further documentation regarding PROFINET interfaces and field distributors. • All technical documentation from SEW‑EURODRIVE is available for download in PDF format from the SEW‑EURODRIVE website: www.sew-eurodrive.de. Compact Manual – PROFINET IO Interfaces, Field Distributors...

  • Page 6: Structure Of The Safety Notes

    General information Structure of the safety notes Structure of the safety notes 1.2.1 Meaning of signal words The following table shows the grading and meaning of the signal words for safety notes. Signal word Meaning Consequences if disregarded  DANGER Imminent hazard Severe or fatal injuries  WARNING Possible dangerous situation...

  • Page 7: Safety Notes

    Safety notes Preliminary information Safety notes Preliminary information The following general safety notes have the purpose to avoid injury and damage to property. They primarily apply to the use of products described in this documentation. If you use additional components also observe the relevant warning and safety notes. Operator's duties Make sure that the basic safety notes are read and observed.

  • Page 8: Designated Use

    Safety notes Designated use Specialist for elec- Any electronic work may only be performed by adequately skilled persons (electric- trotechnical work ally). Qualified electricians in the context of this documentation are persons familiar with electrical installation, startup, troubleshooting and servicing of the product who possess the following qualifications: •...

  • Page 9: Functional Safety Technology

    Safety notes Functional safety technology Functional safety technology The product must not perform any safety functions without a higher-level safety sys- tem, unless explicitly allowed by the documentation. Transport Inspect the shipment for damage as soon as you receive the delivery. Inform the ship- ping company immediately about any damage.

  • Page 10: Electrical Connection

    Safety notes Electrical connection • Above 2000  m asl, the air and creeping distances are only sufficient for over- voltage class II according to EN 60664. If the installation requires overvoltage cat- egory III according to EN 60664 you have to reduce the overvoltages on the sys- tem side from category III to II using additional external overvoltage protection.

  • Page 11: Startup/Operation

    Safety notes Startup/operation 2.10 Startup/operation Observe the safety notes in the chapters "Startup" and "Operation" in the documenta- tion. Make sure that the present transport protection is removed. Do not deactivate monitoring and protection devices of the machine or system even for a test run.

  • Page 12: Type Esignation

    Type esignation Type designation of the PROFINET IO interfaces Type esignation Type designation of the PROFINET IO interfaces 3.1.1 Type designation The following table shows the type designation of the fieldbus interface MFE52B/Z21D as an example: Fieldbus interface MFP.. = PROFIBUS MQP..

  • Page 13: Type Designation Of The Profinet Io Field Distributors

    Type esignation Type designation of the PROFINET IO field distributors Type designation of the PROFINET IO field distributors 3.2.1 Type designation MF../Z.3. The following table shows the type designation for MF../Z.3. field distributors as an ex- ample: Fieldbus interface MFP../MQP.. = PROFIBUS ®...
  • Page 14 Type esignation Type designation of the PROFINET IO field distributors 3.2.3 Type designation MF../MM../Z.7. The following table shows the type designation for MF../MM../Z.7. field distributors as an example: Fieldbus interface MFP../MQP.. = PROFIBUS ® MFE.. = PROFINET IO, EtherNet/IP™ or EtherCAT MFD../MQD..
  • Page 15 Type esignation Type designation of the PROFINET IO field distributors 3.2.4 Type designation MF../MM..Z.8. The following table shows the type designation for MF../MM../Z.8. field distributors as an example: Fieldbus interface MFP../MQP.. = PROFIBUS ® MFE.. = PROFINET IO, EtherNet/IP™ or EtherCAT MFD../MQD..
  • Page 16 Type esignation Type designation of the PROFINET IO field distributors 3.2.5 Type designation MF../MM..Z.9. The following table shows the type designation for MF../MM../Z.9. field distributors as an example: Fieldbus interface MFE.. = PROFINET IO ® MM15D MOVIMOT inverter -503-00 No designation = without inverter ®...

  • Page 17: Mechanical Installation

    Mechanical installation Installation instructions Mechanical installation Installation instructions INFORMATION On delivery, field distributors are equipped with transportation protection covering the plug connector of the outgoing motor circuit (hybrid cable). This only guarantees the degree of protection IP40. To obtain the specified degree of protection, remove the transport protection and plug on the appropriate mating con- nector.

  • Page 18: Fieldbus Interfaces Mf

    Mechanical installation Fieldbus interfaces MF../MQ.. Fieldbus interfaces MF../MQ.. MF../MQ.. fieldbus interfaces can be installed as follows: ® • Installation on MOVIMOT connection box • Installation in the field (= mounting close to the motor) ® 4.2.1 Installation on MOVIMOT connection box 1.
  • Page 19 Mechanical installation Fieldbus interfaces MF../MQ.. ® 2. Mount the fieldbus interface to the MOVIMOT connection box, according to the following figure. . . / M 3.0 – 3,5 Nm 18014399648145931 Compact Manual – PROFINET IO Interfaces, Field Distributors...
  • Page 20 Mechanical installation Fieldbus interfaces MF../MQ.. 4.2.2 Installation in the field The following figure shows the installation of an MF../MQ.. fieldbus interface close to the motor: Z ../ M . . / M 1138749323 [1] Length of screws min. 40 mm Compact Manual –...

  • Page 21: Field Distributor

    Mechanical installation Field distributor Field distributor 4.3.1 Installation of MF../Z.3., MQ../Z.3. field distributors The following figure shows the mounting dimensions for ..Z.3. field distributors: 9007200393500299 4.3.2 Installation of MF../Z.6., MQ../Z.6. field distributors The following figure shows the mounting dimensions for ..Z.6. field distributors: 18014399648277003 Compact Manual –...
  • Page 22 Mechanical installation Field distributor 4.3.3 Installation of MF../MM../Z.7., MQ../MM../Z.7. field distributors The following figure shows the mounting dimensions for ..Z.7. field distributors: 18014399648313483 4.3.4 Installation of MF../MM../Z.8., MQ../MM../Z.8. field distributors (Size 1) The following figure shows the mounting dimensions for ..Z.8. field distributors (Size 1): 18014399648325131 Compact Manual –...
  • Page 23 Mechanical installation Field distributor 4.3.5 Installation of MF../MM../Z.8., MQ../MM../Z.8. field distributors (Size 2) The following figure shows the mounting dimensions for ..Z.8. field distributors (Size 2): 18014399648338187 Compact Manual – PROFINET IO Interfaces, Field Distributors...
  • Page 24 Mechanical installation Field distributor 4.3.6 Installation of MF../MM../Z.9. field distributors The following figure shows the mounting dimensions for ..Z.9. field distributors: 18223713419 Compact Manual – PROFINET IO Interfaces, Field Distributors...
  • Page 25 Mechanical installation Field distributor ® Notes on installation of the MOVIMOT inverters at the MFZ29 field distributor WARNING ® Uncontrolled enabling of an unexpected drive by swapping the MOVIMOT invert- ers. Severe or fatal injuries. ® • Install the MOVIMOT inverters based on the set RS485 address according to the following figure: ®...

  • Page 26: Electrical Installation

    Electrical installation Installation planning taking EMC aspects into account Electrical installation Installation planning taking EMC aspects into account INFORMATION This drive system is not designed for operation on a public low voltage supply system that supplies residential areas. ® MOVIMOT can cause EMC interference within the permitted limit range according to EN 61800-3.
  • Page 27 Electrical installation Installation planning taking EMC aspects into account 5.1.4 Cable glands • Select only cable glands with a shield connected over a large area. Observe the notes regarding the selection of the cable glands. 5.1.5 Cable shields • Must have good EMC properties (high screening attenuation). •...

  • Page 28: Installation Instructions For Fieldbus Interfaces, Field Distributors

    Electrical installation Installation instructions for fieldbus interfaces, field distributors Installation instructions for fieldbus interfaces, field distributors 5.2.1 Connecting supply system leads ® • The nominal voltage and frequency of the MOVIMOT inverter must correspond to the data for the power supply system. •...
  • Page 29 Electrical installation Installation instructions for fieldbus interfaces, field distributors 5.2.2 Permitted connection cross section of terminals Power terminals X1, X21 Control terminals X20 (screw terminals) (cage clamp terminals) Connection cross sec- 0.2 mm – 4 mm 0.08 mm – 2.5 mm tion The permitted tightening torque of the power terminals is 0.6 Nm. ®...
  • Page 30 Electrical installation Installation instructions for fieldbus interfaces, field distributors 5.2.4 Residual current device WARNING No protection against electric shock if an incorrect type of residual current device is used. Severe or fatal injuries. • Use only universal current sensitive residual current devices of type B for invert- ers.
  • Page 31 Electrical installation Installation instructions for fieldbus interfaces, field distributors 5.2.7 Notes on PE connection WARNING Electric shock due to faulty ground connection or faulty equipotential bonding. Severe, fatal injuries • The permitted tightening torque for the retaining screws is 2.0 – 2.4 Nm. •...
  • Page 32 Electrical installation Installation instructions for fieldbus interfaces, field distributors 5.2.8 Looping through the DC 24 V supply voltage in the MFZ.1 module terminal box • There are 2 M4 x 12 studs in the connection area of the DC 24 V supply. The studs can be used for looping the DC 24 V supply voltage.
  • Page 33 Electrical installation Installation instructions for fieldbus interfaces, field distributors 5.2.9 Additional connection options with MFZ.6, MFZ.7 and MFZ.8 field distributors • The connection part of the DC 24 V supply comprises an X29 terminal block with two M4 x 12 studs and a pluggable X40 terminal. 1141387787 •...
  • Page 34 Electrical installation Installation instructions for fieldbus interfaces, field distributors 5.2.10 UL-compliant installation INFORMATION Due to UL requirements, the following chapter is always printed in English independ- ent of the language of the documentation. Field wiring power terminals Observe the following notes for UL-compliant installation: •...

  • Page 35: Connection Of Mfz21 Connection Module With Mfe52 To Movimot

    Electrical installation Connection of MFZ21 connection module with MFE52 to MOVIMOT® Connection of MFZ21 connection module with MFE52 to MOVIMOT® ® Connection of MFZ21 connection module with MFE52 to MOVIMOT ® 5.3.1 MFZ21 connection module with PROFINET IO interface MFE52 connected to MOVIMOT (for a configuration with 6 inputs or with 4 inputs/2 outputs) ®...

  • Page 36: Connection Of Mfz23 Field Distributor With Mfe52

    Electrical installation Connection of MFZ23 field distributor with MFE52 Connection of MFZ23 field distributor with MFE52 5.4.1 MFZ33 connection module with MFE52 PROFINET IO interface and 2 separate DC 24 V circuits (only for a configuration with 4 inputs/2 outputs) MFZ23 4 mm (AWG10) 4 mm (AWG10) 2.5 mm (AWG12) MFE52...
  • Page 37 Electrical installation Connection of MFZ23 field distributor with MFE52 5.4.2 MFZ33 connection module with MFE52 PROFINET IO interface and 1 shared DC 24 V circuit (for a configuration with 6 inputs or with 4 inputs/2 outputs) MFZ23 4 mm (AWG10) 2.5 mm (AWG12) 4 mm (AWG10) MFE52 1 x DC 24 V...

  • Page 38: Connection Of Mfz26, Mfz27, Mfz28 Field Distributors With Mfe52

    Electrical installation Connection of MFZ26, MFZ27, MFZ28 field distributors with MFE52 Connection of MFZ26, MFZ27, MFZ28 field distributors with MFE52 5.5.1 MFZ26, MFZ27, MFZ28 connection modules with PROFINET IO interface MFE52 and 2 separate DC 24 V voltage circuits (only for a configuration with 4 inputs/2 outputs) MFZ26 4 mm (AWG10) MFZ27...
  • Page 39 Electrical installation Connection of MFZ26, MFZ27, MFZ28 field distributors with MFE52 5.5.2 MFZ26, MFZ27, MFZ28 connection modules with PROFINET IO interface MFE52 and 1 shared DC 24 V voltage circuit (for a configuration with 6 inputs or with 4 inputs/2 outputs) MFZ26 4 mm (AWG10) MFZ27...

  • Page 40: Connection Of Mfz29 Field Distributor With Mfe52

    Electrical installation Connection of MFZ29 field distributor with MFE52 Connection of MFZ29 field distributor with MFE52  5.6.1 Terminal positions The following figure shows the position of the terminals and PE connections of the field distributor as an example: 1 2 3 4 5 6 7 8 9 1 2 3 4 5 6 7 8 9 1 2 3 4 5 6 7 8 9 X6_1...
  • Page 41 Electrical installation Connection of MFZ29 field distributor with MFE52 5.6.2 X1, X20, X21 line terminals, 24 V supply MFZ29 connection module with MFE52 PROFINET IO interface and 2 separate DC 24 V circuits (only for a configuration with 4 inputs/2 outputs) MFZ29 4 mm (AWG10) 2.5 mm (AWG12) 4.0 mm (AWG10)
  • Page 42 Electrical installation Connection of MFZ29 field distributor with MFE52 Terminal assignment 24 V distributor terminals Name Direction Function X20 1 24V_C Output 24 V voltage supply for module electronics and sensors jumpered with terminal X21/1 0V24_C 0V24 reference potential for module electronics and sensors jumpered with terminal X21/3 ®...
  • Page 43 Electrical installation Connection of MFZ29 field distributor with MFE52 MFZ29 connection module with MFE52 PROFINET IO interface and 1 shared DC 24 V circuit (for a configuration with 6 inputs or with 4 inputs/2 outputs) MFZ29 4 mm (AWG10) 2.5 mm (AWG12) 4.0 mm (AWG10) MFE52 24V_C...
  • Page 44 Electrical installation Connection of MFZ29 field distributor with MFE52 Terminal assignment 24 V distributor terminals Name Direction Function X20 1 24V_C Output 24 V voltage supply for module electronics and sensors jumpered with terminal X21/1 0V24_C 0V24 reference potential for module electronics and sensors jumpered with terminal X21/3 ®...
  • Page 45 Electrical installation Connection of MFZ29 field distributor with MFE52 Connection variants The MFZ29 field distributor has additional functions for special connections. For more information on the additional connections and the resulting functions, refer to the de- tailed operating instructions. Connection variant parallel connection and ready signal via digital input DI4 (option) The following figure shows the parallel connection of the ready signal of the ®...
  • Page 46 Electrical installation Connection of MFZ29 field distributor with MFE52 Connection variant feedback maintenance switch (MFZ29J design) The following figure shows the additional connection of the MF29J field distributor for the feedback of the maintenance switch. X6_1 18200674699 [1] The cables labeled with "––" are already wired at the factory. Function With this additional connection, the field distributor delivers the status of the mainten- ance switch to the higher-level controller.
  • Page 47 Electrical installation Connection of MFZ29 field distributor with MFE52 Connection variant rapid start/rapid stop via digital output DO0 (option) The following figure shows an example of the additional connection for the simultan- ® eous rapid start and rapid stop of all MOVIMOT drives: X6_1 X6_2...
  • Page 48 Electrical installation Connection of MFZ29 field distributor with MFE52 5.6.3 X6_1, X6_2, X6_3 motor 1 – 3 control terminals Motor 1 – 3 control terminals Name Direction Function ® X6_1 24V P Output 24 V voltage supply for TH, L and R of the MOVIMOT inverter X6_2 ®...

  • Page 49: Connection Of The Inputs/Outputs Of The Mfe52 Fieldbus Interface

    Electrical installation Connection of the inputs/outputs of the MFE52 fieldbus interface Connection of the inputs/outputs of the MFE52 fieldbus interface The fieldbus interface is connected via terminals or M12 plug connectors. 5.7.1 Connection of inputs/outputs via terminals For fieldbus interfaces with 4 digital inputs and 2 digital inputs/outputs: MFZ.1 MFZ.6 in combination with...
  • Page 50 Electrical installation Connection of the inputs/outputs of the MFE52 fieldbus interface Terminal assignment Name Direction Function X20 31 DIO4 Input Sensor DI4 switching signal Output Actuator DO0 switching signal GND2 – 0V24 reference potential for sensor DI4 – 0V24 reference potential for actuator DO0 DIO5 Input Sensor DI5 switching signal...
  • Page 51 Electrical installation Connection of the inputs/outputs of the MFE52 fieldbus interface 5.7.2 Connection of inputs/outputs via M12 plug connectors For MFE52A/MFE52B fieldbus interfaces with 4 digital inputs and 2 digital inputs/outputs: NOTICE Loss of the guaranteed degree of protection if the screw plugs in the unused M12 connections are not installed or not installed correctly.

  • Page 52: Connection Of Profinet Io

    Electrical installation Connection of PROFINET IO Connection of PROFINET IO The following figure shows the connections of the PROFINET IO bus: 9007202600365067 [1] X11, PROFINET IO connection, port 1 [2] X12, PROFINET IO connection, port 2 The following table shows the pin assignment of the PROFINET IO ports X11 and X12: Function PROFINET IO interface...
  • Page 53 Electrical installation Connection of PROFINET IO 5.8.1 The integrated Ethernet switch You can use the integrated Ethernet switch to achieve line topologies known from the fieldbus technology. Other bus topologies, such as star or tree, are also possible. INFORMATION The number of Industrial Ethernet switches connected in line affects the telegram runtime.

  • Page 54: Hybrid Cable Connection

    Electrical installation Hybrid cable connection Hybrid cable connection ® 5.9.1 Hybrid cable between MFZ.3. or MFZ.6. field distributor and MOVIMOT ® The following figure shows the hybrid cable for connecting the MOVIMOT drive part number (01867253). MFZ.3 MFZ.6 9007200401506827 The following table shows the terminal assignment of the hybrid cable in the ®...
  • Page 55 Electrical installation Hybrid cable connection 5.9.2 Hybrid cable between MFZ.7. or MFZ.8. field distributor and AC motors The following figure shows the hybrid cable for connecting the AC motor part number 01867423. MFZ.8 MFZ.7 9007200402006667 The following table shows the terminal assignment of the hybrid cable in the motor ter- minal box: Terminal assignment Motor terminal...
  • Page 56 Electrical installation Hybrid cable connection 5.9.3 Hybrid cable between MFZ.9. field distributor and AC motors The following figure shows the hybrid cable for connecting the AC motor part number 08184380. MFZ.9 18205192331 The following table shows the terminal assignment of the hybrid cable in the motor ter- minal box and in the field distributor: Terminal assignment Motor ter-...

  • Page 57: Pc/Laptop Connection

    Electrical installation PC/laptop connection 5.10 PC/laptop connection The fieldbus interfaces have a diagnostic interface (RJ10 plug connector) for startup, parameter setting, and service. The diagnostic interface is located underneath the screw plug of the fieldbus interface. You must remove the screw plug before plugging in the connector into the diagnostic interface.

  • Page 58: Wiring Check

    Electrical installation Wiring check 5.11 Wiring check INFORMATION For ensuring the isolation and the effectiveness of preventive measures, you have to perform the checks of the valid and applicable standards (e.g. EN  60204-1 or EN 61800-5) after any wiring work for installation, conversion, repair, etc. In order to prevent injury to persons or damage to the plant, check the wiring as de- scribed below before you connect the voltage supply for the first time: •...

  • Page 59: Startup

    Startup Startup instructions Startup Startup instructions WARNING Risk of crushing due to missing or defective protective covers. Severe or fatal injuries. • Install the protective covers of the plant according to the instructions, see the op- erating instructions of the gear unit. •...
  • Page 60 Startup Startup instructions INFORMATION • Switch off the DC 24 V voltage supply before removing/installing the fieldbus inter- face. • The incoming and outgoing PROFINET IO bus cables are connected to the module electronics. If the module electronics are removed, the PROFINET IO line is interrupted.

  • Page 61: Tcp/Ip Addressing And Subnetworks

    Startup TCP/IP addressing and subnetworks TCP/IP addressing and subnetworks 6.2.1 Introduction The settings for the address of the IP protocol are made using the following paramet- • MAC ID • IP address • Subnet mask • Standard gateway The addressing mechanisms and subdivision of the IP networks into subnetworks are explained in this chapter to help you set the parameters correctly.
  • Page 62 Startup TCP/IP addressing and subnetworks 6.2.4 Network classes The first byte of the IP address determines the network class and as such represents the division into network addresses and node addresses. Range of val- Network Complete Explanation class network address Byte 1 (example) 0 –...

  • Page 63: Setting The Ip Address Parameters

    Startup Setting the IP address parameters 6.2.6 Standard gateway The standard gateway is also addressed via a 32-bit address. The 32-bit address is represented by 4 decimal numbers separated by decimal points. Example: 192.168.10.1 The standard gateway establishes a connection to other networks. In this way, a net- work node that wants to address another node can use logic AND operation with the IP address and the subnet mask to decide whether the desired node is located in the same network.

  • Page 64: Startup Procedure

    Startup Startup procedure Startup procedure INFORMATION ® This chapter describes the startup procedure for MOVIMOT MM..D in Easy mode. ® For information on the startup of MOVIMOT MM..D in Expert mode, refer to the ® "MOVIMOT MM..D" operating instructions. WARNING Electric shock from capacitors that have not been fully discharged.
  • Page 65 Startup Startup procedure ® 6. Set the maximum speed using setpoint potentiometers f1 of all MOVIMOT invert- ers. 2 3 4 5 6 7 8 9 10 27021598093635979 [1] Potentiometer setting NOTICE! Loss of warranted degree of protection if the screw plugs of the f1 set- point potentiometer or the X50 diagnostic interface are installed incorrectly or not ®...
  • Page 66 Startup Startup procedure CW/stop CCW/stop Meaning Not activated Not activated • The device is inhibited or the drive is brought to a stop.   WARNING!  Uncontrolled enable of an unexpected drive due to incorrect ad- dress setting. Severe or fatal injuries. Make sure that the S1/1 and S1/2 DIP switches on the MFE..
  • Page 67 Startup Startup procedure 15. Switch on the DC  24  V supply voltage for the MFE.. fieldbus interface and the ® MOVIMOT inverter. ð Startup has been completed successfully when the "MS" LED at the MFE.. fieldbus interface lights up green. ð The red "SYS-F" LED is not lit. 16.

  • Page 68: Function

    Function Meaning of the LED display Function Meaning of the LED display The MFE PROFINET IO interface has 5 LEDs for diagnostic purposes. • The "RUN" LED indicates the operating state of the MFE fieldbus interface. • The "BUS-F" LED for displaying errors in the PROFINET IO. •...
  • Page 69 Function Meaning of the LED display 7.1.2 "RUN" LED The following table shows the statuses of the "RUN" LED: Meaning Measure BUS-F Green MFE component hardware is OK. Lights up Green Proper operation. Lights up MFE is currently exchan- ging data with the PROFINET master (data exchange).
  • Page 70 Function Meaning of the LED display 7.1.3 "SYS-F" LED The following table shows the statuses of the "SYS-F" LED: Meaning Measure SYS-F Standard operating state. MFE is currently exchanging data with ® the MOVIMOT inverter. MFE cannot exchange data with Check the RS485 wiring between ®...

  • Page 71: Performance Configuration Mfz29 Field Distributor With 3 Movimot Drives

    Function Performance configuration MFZ29 field distributor with 3 MOVIMOT® drives Performanc e c onfigurati on MFZ29 field distributor with 3 MOVIMOT® drives ® Performance configuration MFZ29 field distributor with 3 MOVIMOT drives ® S1 continuous The total power of all connected MOVIMOT drives may not exceed the limit of 3.3 kW duty in S1 continuous duty.

  • Page 72: Service

    Service Error list for fieldbus interfaces Service INFORMATION ® For information on service and maintenance of the MOVIMOT inverters, refer to the respective operating instructions. Error list for fieldbus interfaces Code Meaning Response Possible cause Measure EEPROM Rapid stop of Error while accessing •...
  • Page 73 Declaration of conformity Declaration of conformity EU Declaration of Conformity Translation of the original text 900030310/EN SEW-EURODRIVE GmbH & Co. KG Ernst-Blickle-Straße 42, D-76646 Bruchsal declares under sole responsibility that the following products ® Frequency inverters of the product series MOVIMOT MM..D-..3-..
  • Page 74 Declaration of conformity EU Declaration of Conformity Translation of the original text 900040310/EN SEW-EURODRIVE GmbH & Co. KG Ernst-Blickle-Straße 42, D-76646 Bruchsal declares under sole responsibility that the following products Field distributors of the series MF../Z.3. MQ../Z.3. MF../Z.6. MQ../Z.6. MF../Z.7.
  • Page 76 SEW-EURODRIVE—Driving the world SEW-EURODRIVE GmbH & Co KG Ernst-Blickle-Straße 42 76646 BRUCHSAL GERMANY Phone +49 7251 75-0 Fax +49 7251 75-1970 sew@sew-eurodrive.com www.sew-eurodrive.com...
