Fig. 95 Dialogue "Select temperature unit"
On selecting the "Unit.." menu item, the dialogue shown in Fig. 95 is displayed. Here, there is a choice of
the temperature units "°Celsius", "°Fahrenheit" and "Kelvin".
Fig. 96 Dialogue "Accumulator state"
Select the "Battery.." menu item to check the battery status. Thereupon, the operating data and the
display of the current battery supply are listed in a message window (see Fig. 96) by means of the
FireWire (IEEE 1394)-interface.
Fig. 97 Dialogue "System info"
Information about the system can be displayed in the menu item "Systeminfo..". The actual version of
the firmware can be identified as well as the current version.
C Camera-Version
F FPGA-Version
I IFC-Version
K KCP-Version
O OMI-Version
Serial number of the camera
The communication via the serial connection can be activated/deactivated by checking the menu item
"RS232".
