Oracle X6-2-HA Deployment And User's Manual page 68

Password: Provide a password for the database.
h.
Deployment: Select a deployment type from the list. The options are RAC,
i.
RAC-One, or SI (single instance database). If you select a single instance
database, then select the node for the SI database deployment.
If you select a single instance database, then you have the option to create
the database on either Node0 or Node1. The default is Node0.
Shape: Select a database shape from the list.
j.
In the Database Class field, select a database class from the drop-down list. If
k.
an option is not available in the list, it is not supported for the database edition
on the Oracle Database Appliance or the version that you selected. The
default is OLTP.
In the Storage field, select ACFS or ASM from the drop-down list. The default
l.
is Oracle ASM.
Only Oracle 18c, 12.2, and 12.1 databases can use Oracle ASM storage.
Oracle Database 11.2 is only supported on Oracle ACFS.
If you select the storage as ASM, and the Database Version is 12.2 or later,
m.
and you specified the disk group redundancy as Flex, then you can select the
Database Redundancy value as Mirror or High.
You can choose Oracle ACFS storage for all database versions, but if you
select Oracle ACFS storage, then you cannot specify the database
redundancy. If your disk group redundancy is Flex, and you choose Oracle
ACFS storage for the database, then the database redundancy is set to Mirror.
Storage: Select ACFS or ASM.
n.
Data Files on Flash Storage: Select Yes or No.
o.
This option is only available if the HA system has HDD storage drives.
Configure EM Express: Select Yes or No.
p.
Select Yes to configure the Oracle Enterprise Manager Database Express
(EM Express) console for Oracle Database 12.2.1.0 or 12.1.0.2 or the
Database Control Console for Oracle Database 11.2.0.4. Selecting Yes
enables you to use the console to manage the database.
Characterset: Select a characterset.
q.
National Characterset: Select a national characterset.
r.
Language: Select the database language.
s.
Territory: Select a territory or location from the list.
t.
(Optional) Configure and enable Oracle ASR on the ASR page.
10.
You can configure and enable Oracle Auto Service Request (Oracle ASR) now or
later:
• To not enable Oracle ASR during deployment, select No and click Submit.
After deployment, you can configure an internal Oracle ASR or register with an
external Oracle ASR Manager from either the Web Console or command-line
interface.
– Internal Oracle ASR: choose to configure Oracle ASR Manager on Oracle
Database Appliance or use Oracle ASR Manager configured on another
server in the same network as your appliance.
Chapter 4
Creating the Appliance
4-11
