Expand Host Management in the left menu of the ILOM Remote Console tab.
a.
Click Host Control.
b.
Select CDROM from the Next Boot Device menu, then click Save.
c.
Power cycle the system.
6.
Click Power Control in the Host Management menu.
a.
Select Power Cycle.
b.
When the node comes back after the power cycle, reimaging starts automatically.
It can take a couple of hours to reimage. The Running Post-Install scripts page is a
static page and might give the impression that the reimaging process is not
progressing. The post-install process during reimaging will wait until the
synchronization between the partitions of the two mirrored local hard disks is
complete, which can take 15 to 20 minutes to complete.
To check the progress of resynchronization, press the ALT-F2 key combination to
open a second console and enter the following command:
# cat /proc/mdstat
When the resynchronization is complete, reimaging is completed and the machine
restarts.
Repeat Steps 1 through 6 for Node1.
7.
Reimaging is node-specific. You must reimage both nodes. You can reimage both
nodes at the same time.
Verify that the host name in the Console is oak1 for Node0 and oak2 for Node1.
8.
If the host name is something other than oak1 or oak2, then reboot the node. You
might need to reboot more than once.
Once the image is completed on both nodes, you will see the screen with oak1 for
Node0 (sc0).
Note: Ensure that you provide the node numbers for both nodes during the reboot.
Specify node number 0 for the first node and node number 1 for the second node.
Use the command oakcli configure firstnet to configure a local or
9.
global network. For local network, run the command on both nodes. For global
network, run the command on any one node.
The global configuration sets the initial public network for both the nodes on
Oracle Database Appliance, enabling you to download the deployment software
onto the appliance.
# oakcli configure firstnet
Configure the network for the node(s)(local, global) [global]:
The network configuration for both nodes:
Domain Name: test.com
DNS Server(s): Primary Dns Server: 192.0.2.18
Node Name Host Name
0 node1
1 node2
Choose the network interface to configure (net1, net2) [net1]:
Secondary Dns Server: 192.0.2.19
Tertiary Dns Server:
