Min–Max Setup - Arbiter Systems Portable Power Sentinel 933A Operation Manual

4.2 Min–Max Setup
Use the Min–Max Setup, within any data display screen, to view the
normal, minimum, maximum and average data values. To restart Min–
Max accumulation, press the RESTART MIN/MAX in the Min–Max
menu.
Figure 4.2: Min–Max
Setup
To select Min / Max / Average or Normal:
1. Press the DISPLAY key and choose 0-Tabular (or other Data Type
selection key) to access the selections from the Min–Max menu.
2. Press the Min–Max SELECTION soft key to activate the Min–Max
soft menu at the bottom of the display.
3. To view the minimum, maximum or average results, press any Min–
Max function soft key below the display.
4. Press the RESTART Min–Max soft key to reset the minimum,
maximum and average values to zero, and begin storing new values.
5. Press the EXIT Min–Max to return to the Phase A Results screen.
Note: Remember that the Min–Max function is always active from the
time that the 933A is powered ON. It may be important to press the
RESTART Min–Max if you are starting a new measurement and do not
want any previous measurements (startup conditions, noise, etc.) included
with your new measurement.
48
