7.5

Auxiliary I/O Module

Triggering with the Auxiliary I/O Module is very straightforward and is
easy to set up. See Page 11 for accessory information.
7.5.1 Auxiliary I/O Module Description
The Auxiliary I/O Module has three contact outputs and four event inputs.
One of the output contacts is a solid state set (KYZ-rated) and the other
two are standard Form C mechanical contacts. The Event Inputs are
separated into three groups: one set rated at between 24 to 240 Vdc, one
set rated at TTL-level voltages (5 Vdc), and two sets are contact closure.
Signals are connected to the module with ring terminals and connection
to the Model 933A is by a nine-foot cable assembly.
The Auxiliary I/O Module is powered from the Model 933A and must be
installed with the Model 933A powered OFF.
7.5.2 Configuring Event Inputs
1. Open the Auxiliary I/O connector cover on the 933A and slide in
the plug on the end of the cable into the connector until it snaps in
position.
2. Power on the 933A.
3. Press the SETUP key > 7
4. Press the EVENT SETTINGS soft key and choose the Event Input
number with the right/left cursor keys.
5. Select the Mode (depends on the Event Input number), Max Logging
Time (MaxLogTime) and Post Fault Time (PostFault).
6. Press the BACK soft key, and remember to Save Settings.
Terminology
In the Event Input Setup Window of the 933A are several terms: EventIn-
put, Mode, MaxLogTime and PostFault.
EventInputs: 1 4
Trigger Setup.
