6.3.7

Lists of Broadcast Values

Data values available when selecting Basic Data from the Broadcast
Toolbar are listed below.
Basic Data
55 Values
1. A, B and C phase voltages and currents
angle
2. Positive, Negative and Zero Sequence Voltages and Currents
magnitude and phase angle.
3. Active Power (Watts) for A, B, C phases and Total.
4. Apparent Power (VA) for A, B, C phases and Total.
5. Reactive Power (VAR) for A, B, C phases and Total.
6. Power Factor (PF) for A, B, C phases and Total.
7. Q for A, B, C phases and Total.
8. System Frequency (Hz)
9. System Frequency Deviation
10. System Frequency Rate (df/dt)
11. System Time Deviation, Seconds
12. System Time Deviation, Cycles
Energy Data
40 Values
1. Watt-Hours, Delivered and Received: A, B, C phases and Total
2. VAR-Hours, Q1
3. VA-Hours, Delivered and Received: A, B, C phases and Total.
4. Q-Hours, Delivered and Received: A, B, C phases and Total.
Harmonics, Fundamental to the 50th
1. Voltage: A, B and C phases
2. Current: A, B and C phases
Harmonic Summary
Includes RMS THD, RMS K, THD F, THD T and K-Factor for each
voltage and current phase.
Waveform Data
6 Values
Includes 3 phases for voltage and current.
Phasor Data
6 Values
Includes 3 phases for voltage and current.
Q4, A, B, C phases and Total
600 Values
magnitude and phase angle.
magnitude and phase angle.
30 Values
97
magnitude and phase
