Sliding Reference
Set the Reference Format to Sliding when you want to follow daily
variations in voltage or current that do not require a trigger unless it
exceeds the expected rate of change.
requirements the line voltage sags during the day and swells during the
night, you might want to use a sliding reference to avoid unnecessary
triggers. A sliding reference would generate a trigger only if the voltage
unexpectedly sags or swells at a rate greater than expected.
Calculating a Sliding Reference Voltage
Per the specification IEC61000-4-30, the sliding reference voltage is
calculated by using equation 7.1; it is of first-order and uses a one-minute
time constant.
(7.1) U = 0.9967
sr(n)
Where
U is the present value of the sliding reference voltage;
sr(n)
U is the previous value of the sliding reference voltage; and
sr(n 1)
U is the most recent 10/12-cycle r.m.s. value.
(10/12)
Note that even though the specification defines the input signal (U) as a
voltage, it has been applied in the 933A to include measured input currents,
as calculated using the same formula, with U as a current.
Logging Time
There are two available settings of which you can choose to control how the
933A logs one-second data when a trigger becomes active: MaxLogTime,
and PostFault.
MaxLogTime: defines the number of seconds to record data during which
the specific trigger is active (i.e. faulted). Setting MaxLogTime to 10
seconds will cause the 933A to record 10, once-per-second records after a
trigger becomes active.
PostFault: defines the number of seconds that the 933A records data
after the trigger becomes inactive (i.e. after the fault has disappeared).
For example, if due to usage
U + 0.0033 U
sr(n 1) (10/12)
