Arbiter Systems Portable Power Sentinel 933A Operation Manual page 161

Table 9.2: Signal Functions Available for Triggering
ID# Function
0 Off
1 Voltage
2 Current
3 Active Power (Watts)
4 Relative Power (VARs)
5 Apparent Power
6 Power Factor (PF)
7 Sequence Voltage
Components
8 Sequence Current
Components
9 Phase Bal. Ratio, Derived
from sequence components
10 Frequency and Time
11 THD Voltage
12 THD Current
13 Harmonic V
14 Harmonic I
15 K-Factor, voltage
16 K-Factor, current
17 Flicker, instantaneous,
voltage
18 Flicker, PST, voltage
19 Flicker, instantaneous
current
20 Flicker, PST, current
21-25 Reserved
26-31 Transient Detector,
channel 0-5
1. Average or maximum of 3 voltage channels in 3P4W3E and 3P3W2E input mode,
1 channel in 1P2W1E mode, and 2 channels in other modes. In 3P3W2E mode, the
voltage VAC is derived internally by point-by-point calculation after A/D conversion.
The voltage VB, synthesized internally in 3P4W21/2E mode, does not correspond to
an actual physical quantity and is not included in the analysis, although measurements
can be made on the synthesized signal.
2. Average or maximum of 3 current channels in 3-phase modes, 1 channel in 1P2W3E
mode, and 2 channels in other modes. In 3P3W2E mode, the current Ib is derived
internally by point-by-point calculation after A/D conversion.
3. Total of 3 elements in 3P4W3E and 3P4W21/2E modes, 1 element in 1P2W1E mode,
and 2 elements in other modes.
Rate Channels
Available
20/sec N/A
20/sec A,B,C, Ave.
20/sec A,B,C, Ave.
20/sec A,B,C, Total
20/sec A,B,C, Total
20/sec A,B,C, Total
20/sec A,B,C, Total
20/sec Zero, Pos., Neg.
20/sec Zero, Pos., Neg.
20/sec Zero, Pos., Neg.
20/sec Freq., DF, df/dt, DT
1/sec A,C,B, max (A,C,B)
1/sec A,C,B, max (A,C,B)
1/sec A,C,B, max (A,C,B)
1/sec A,C,B, max (A,C,B)
1/sec A,C,B, max (A,C,B)
1/sec A,C,B, max (A,C,B)
1/sec A,C,B, max (A,C,B)
1/sec A,C,B, max (A,C,B)
1/sec A,C,B, max (A,C,B)
1/sec A,C,B, max (A,C,B)
TBD TBD
20/sec Bound, rate/ch., osc.
143
1
2
3
3
3
3
1
2
1
2
1
2
1
1
2
2
