toggle when the count register increases on a rotation to the right. Upon
rotating to the left,
If the processor pins are needed for the expansion interface II, disconnect
the rotary encoder switch via the four-position rotary/NAND enable
switch ( ).
SW13
(SW13)" on page 2-14.
An example program is included in the EZ-Board installation directory to
demonstrate how to set up and access the rotary encoder interface.

Ethernet Interface

The ADSP-BF526 processor has an integrated Ethernet MAC with media
independent interface (MII) and reduced media independent interface
(RMII), which connects to an external PHY. The EZ-Board provides a
SMSC LAN8700 RMII Ethernet PHY with Auto-MDIX, fully compliant
with IEEE 802.2/802.2u standards. The SMSC LAN8700 chip supports
10BASE-T and 100BASE-TX operations. The part is attached gluelessly
to the processor.
The Ethernet signals are shared with NAND flash; by default, the Ether-
net mode is set
(SW12)" on page 2-14

It is important not to run code that accesses NAND flash while
using the Ethernet interface.
The Ethernet mode is set by the
auto negotiation with settings
CS Switch (SW11)" on page 2-13
The Ethernet chip is pre-loaded with a MAC address. The MAC address
for the EZ-Board is stored in the configuration flash section of the parallel
flash memory and can be found on a sticker on the bottom side of the
board.
