Ref. Qty. Description
46 1 IDC 3X2
IDC3X2
47 1 PWR .65MM
CON045
48 1 IDC 4X2
IDC4X2
49 1 5A RESETABLE
FUS005
50 1 ROTARY
SWT023
51 2 3.5MM
DUAL_STEREO
CON050
52 1 USB_MINI-AB
5PIN CON052
53 1 RJ45 8PIN
CON_RJ45_12P
54 5 MOMENTARY
SWT024
55 1 ROTARY_ENC_
EDGE SWT025
56 1 QMS 52x2
QMS52x2_SMT
57 1 IDC 16x2
IDC16x2_SMT
58 2 IDC 25x2
IDC25x2_SMTA
59 1 IDC 35x2
IDC35x2_SMTA
60 1 IDC 7x2
IDC7x2_SMTA
A-4
Reference Designator
JP15
P14
JP8
F1
SW1
J3-4
P8
J5
SW15-19
SW5
J1
P9
P2,P4
P3
P1
ADSP-BF526 EZ-Board Evaluation System Manual
Manufacturer Part Number
BURG 54102-T08-03LF
DIG CP1-023-ND
SULLINS GEC04DAAN
MOUSER 650-RGEF500
DIGI-KEY 563-1047-ND
SWITCH- 35RAPC7JS
CRAFT
MOLEX 56579-0576
DIGI-KEY 380-1022-ND
PANASONIC EVQ-Q2K03W
PANASONIC EVQ-WKA001
SAMTEC QMS-052-06.75-L-
D-A
SAMTEC TSM-116-01-T-DV
SAMTEC TSSH-125-01-L-DV-A
SAMTEC TSSH-135-01-L-DV-A
SAMTEC TSM-107-01-T-DV-A
