Connectors
or alternate retention connectors. For more information about the land
grid array, consult the Tektronix Web site.
Table 2-14. DMAX Land Grid Array Connectors (P5–7)
Part Description
Primary retention
Alternate retention

USB OTG Connector (P8)

The pinout of the
Schematic" on page
Part Description
USB 5-pin mini AB
3M mini USB 2.0 cable

Host Interface Connector (P9)

The pinout of the
Schematic" on page
Part Description
IDC header
IDC socket
2-34
Manufacturer
TEKTRONIX
TEKTRONIX
connector can be found in
P8
B-1.
Manufacturer
MOLEX
Mating Cable (shipped with EZ-Board)
ASSMANN
connector can be found in
P9
B-1.
Manufacturer
SAMTEC
Mating Connector
SAMTEC
ADSP-BF526 EZ-Board Evaluation System Manual
Part Number
020290800
020291000
"ADSP-BF526 EZ-Board
Part Number
56579-0576
AK672M/2-3
"ADSP-BF526 EZ-Board
Part Number
TSW-116-26-T-D
TSW-116-01-T-D
