Ethernet Connector (J5); Battery Holder (J6); Jtag Connector (P1) - Analog Devices ADSP-BF526 EZ-Board Manual

Connectors

Ethernet Connector (J5)

Part Description
RJ-45 Ethernet jack
Cat 5E patch cable

Battery Holder (J6)

Part Description
16 mm battery holder
3V 125MAH 16 mm LI-COIN

JTAG Connector (P1)

The JTAG header is the connecting point for the JTAG interface to the
ADSP-BF526 processor. The standalone debug agent requires both con-
nectors and
P1
Pin 3 is missing to provide keying. Pin 3 in the mating connector should
have a plug.
When using an emulator with the EZ-Board, the standalone debug agent
must be removed. Follow the installation instructions provided in
Install and Session Startup" on page 1-5
sion Startup" on page
2-32
Manufacturer
STEWART
Mating Cable (shipped with EZ-Board)
RANDOM
Manufacturer
MEMORY PROTECTION
Mating Battery (shipped with EZ-Board)
PANASONIC
.
ZP1
1-9, using
P1
ADSP-BF526 EZ-Board Evaluation System Manual
Part Number
SS-6488-NF
PC10/100T-007
Part Number
BH600
CR1632
or "VisualDSP++ Install and Ses-
as the JTAG connection point.
"CCES
