Ref. Qty. Description
13 1 25MHz OSC013
14 1 24MHz OSC013
15 1 12MHz OSC014
16 1 SI1012R SC-75A
17 4 SI2333DS
SOT23D
18 1 GTL2002DC
VSSOP8
19 4 FXL2T245
MAC010A
20 1 FXL4T245
MLP014A
21 1 MIC2025-2
SOIC8
22 1 NAND02
TFBGA63_80_95
X120
23 1 MT48H32M16
VFBGA54_80x90
24 1 ADSP-BF526
BGA208
25 1 ADP1715
MSOP8
26 1 ADP1710 TSOT5
27 1 ADR550B
SOT23-3
28 1 ADP2291
MSOP8
29 1 ADP2105-1.8V
LFCSP16
A-2
Reference Designator
Y1
Y2
Y3
Q1
Q2-4,Q6
U39
U4,U32,U40-41
U3
U2
U15
U14
U1
VR5
VR10
U35
U37
VR3
ADSP-BF526 EZ-Board Evaluation System Manual
Manufacturer Part Number
DIGI-KEY 535-9140-1-ND
DIGI-KEY 535-9138-2-ND
DIGI-KEY 535-9100-1-ND
VISHAY SI1012R-T1-E3
VISHAY SI2333DS-T1-E3
DIGI-KEY 568-1869-1-ND
FAIRCHILD FXL2T245L10X
SEMI
FAIRCHILD FXL4T245BQX
SEMI
MICREL MIC2025-2YM
NUMONYX NAND02GR3B2CZ
A6E
DIGI-KEY 557-1390-1-ND
ANALOG ADSP-BF526BBCZ-
DEVICES 4AX
ANALOG ADP1715ARMZ-R7
DEVICES
ANALOG ADP1710AUJZ-R7
DEVICES
ANALOG ADR550BRTZ-REEL7
DEVICES
ANALOG ADP2291ARMZ-R7
DEVICES
ANALOG ADP2105ACPZ-1.8-R7
DEVICES
