Ref. Qty. Description
30 1 ADP2105-3.3V
LFCSP16
31 1 ADM13305-4
SOIC8
32 1 AD5258
MSOP10
33 1 ADM1385ARSZ
SSOP20
34 1 AD8619ARUZ
TSSOP14
35 2 ADP1610
MSOP8
36 1 SSM2603 ICS009
37 1 ADP120-AUJZ18
R7 TSOT5
38 1 DIP8 SWT016
39 1 DIP6 SWT017
40 10 DIP4 SWT018
41 1 DB9 9PIN
CON038
42 10 IDC 2X1
IDC2X1
43 5 IDC 2X1
IDC2X1
44 6 IDC 3X1
IDC3X1
45 20 IDC
2PIN_JUMPER_
SHORT
ADSP-BF526 EZ-Board Evaluation System Manual

ADSP-BF526 EZ-Board Bill Of Materials

Reference Designator
VR2
U22
U34
U21
U36
VR7,VR9
U31
VR1
SW21
SW20
SW2,SW4,SW6-7,
SW9-14
J2
P10-13,P15,P19,P21-
23,P25
JP2,JP7,JP9,JP14,JP16
JP3,JP5-6,JP10-11,JP17
SJ1-9,SJ11-14,SJ16,
SJ21-22,SJ26-29
Manufacturer Part Number
ANALOG ADP2105ACPZ-3.3-
DEVICES R7
ANALOG ADM13305-4ARZ
DEVICES
ANALOG AD5258BRMZ10
DEVICES
ANALOG ADM1385ARSZ
DEVICES
ANALOG AD8619ARUZ
DEVICES
ANALOG ADP1610ARMZ-R7
DEVICES
ANALOG SSM2603CPZ-R2
DEVICES
ANALOG ADP120-AUJZ18R7
DEVICES
C&K TDA08H0SB1
CTS 218-6LPST
ITT TDA04HOSB1
NORCOMP 191-009-213-L-571
FCI 90726-402HLF
FCI 90726-402HLF
FCI 90726-403HLF
DIGI-KEY S9001-ND
