Cable Connect Table with Terminal Server
Async Port
Diagnostic
1
2
3
4
5
6
7
8
9
10
11
12
16
10/100 Ethernet Port
October 2014
Destination
Speech Server #1 COM1
MpsAp1 LOM / Serial Mgmt
MpsAp2 LOM / Serial Mgmt
MpsAP1 tty
MpsAp2 ttyb
MpsAp3 LOM
MpsAp4 LOM
MpsAp5 LOM
MpsAp6 LOM
MpsAp7 LOM
MpsAp8 LOM
MPS/VRC #1 Console
MPS/VRC #2 Console
BPS-2000 Serial Port
BPS-2000 Ethernet Port
Avaya Media Processing Server 1000 Hardware Installation and Maintenance
Comments? infodev@avaya.com
Cable Connect Table with Terminal Server
Cable Type
MRV #151-3028
RJ45M-RJ45M Rollover
RJ45M-RJ45M Rollover
RJ45M-RJ45M Rollover
RJ45M-RJ45M Rollover
RJ45M-RJ45M Rollover
RJ45M-RJ45M Rollover
RJ45M-RJ45M Rollover
RJ45M-RJ45M Rollover
RJ45M-RJ45M Rollover
RJ45M-RJ45M Rollover
MPS Console Cable
MPS Console Cable
Ethernet W/DB9 Adapter
Std. Ethernet Cable, 1 to 1
61
