5 . 8 S y s t e m D i s p l a y s
Please see page 10, "Text Programming" section for this function as it requires programming
partition text, sign on messages etc.

5.8.1 Partition Texts

You may choose how you want each Partition/Level Arm to be displayed, i.e. "Partition A" may be
used to fully arm a house therefore you may want to call it "Full House Arm" for example. You can
have a maximum of 16 characters on the display.

5.8.2 Sign On Message

The Sign on Message is the main display on the top line in disarmed mode.

5.8.3 Site Name

The Site Name is used as a "Site Reference" which if used must be also used within the PCX
Upload/Download Software in order for the software to connect to the PCX system.

5.8.4 Display When Arm / Display Alarms / Display HU's

If this option is enabled, then the Partition Text will be displayed on the LCD keypad once the
system is fully armed. (The default is No – not compliant with PD6662/EN50131-1)
If Display Alarms/HU's are enabled, they will show any alarms that are activated before a valid
user code/tag is entered. If Display Inputs is enabled, any inputs activated in day mode will be
displayed.

System Displays

Using the and
DISPLAYS?'
Press the key
Partition Text
Enter the desired text for the partition; press the
key to enter the text for all other partitions.
You can also add/change the text for "Full"
partition arming, the sign on message and the
site name label.
Press the key once you have changed each
text display.
Display When Arm
Enter : for No
Enter : for Yes. Press the
You will be returned to the Engineer Menu.
RINS868-6
V i s u a l K e y p a d P r o g r a m m i n g P r o c e d u r e
S Y S T E M D I S P L A Y S
keys, scroll to 'SYSTEM
key.
PCX 256 PROGRAMMING MANUAL
Page: 29
