The controller provides 'Alarm' and 'Can Set' outputs dedicated to that sub-partition. It also
provides relevant indications, including Set/Unset status, so should always be located adjacent to
the controlling Keyswitch where this is used.
If the option 'Auto Readmits when set' is selected as 'WHEN AREA SET' then the sub-partition will
always set when the area in which it located is set. If selected as 'NEVER' it will always require
manual setting.
The sub-partition must ALWAYS be unset manually.
An additional option is available the 'SITE OPTIONS' menu, to permit a 'misoperation' (abort)
signal to be generated by silencing an alarm at the Controller.
Operation of a sub-partition
Action
Normal (unset) status
Sub-partitions input triggered
Attempt to set sub-partitions
with input in fault
Set sub-partition with no faults
Sub-partition input triggered
Sub-partition Controller unset
Valid code entered at a
Keypad whilst alarm running
V i s u a l K e y p a d P r o g r a m m i n g P r o c e d u r e
Assign Keypads/Readers
Using the
and
KEYPADS/READERS?'
Press the
key
Address
Enter the address of the keypad/reader you wish
to assign. Press the
Type
Enter
: for Reader
Press the
key
RINS868-6
Status
Detectors within sub-
partitions are inactive
No response
-
sub-partition sets (detectors
live)
Alarm generated
sub-partition unsets
Alarm silenced
A S S I G N K E Y P A D S / R E A D E R S
S u b P a r t i t i o n C o n t r o l
keys, scroll to 'ASSIGN
key
PCX 256 PROGRAMMING MANUAL
Notes
'Unset' indication lit
'Fault' LED flashes and
intermittent tone to
indicate 'cannot set'
'Unset' indication goes out
'Alarm' LED lights, alarm
tone generated
'Unset' indication lights
Sub-partition remains set.
Page: 27
