PCX 256 PROGRAMMING MANUAL
Engineer Tests
Using the and
'ENGINEER TESTS?' Press the
Sound To Play
Press the key to select which sound which
sound you would like to hear. Press the
Walk Test
Press the key to enter Walk Test.
Select the partitions to be tested. Press the
key
The display will scroll through all the inputs not
yet tested. Walk test each input. As each input is
triggered, a chime will sound and that input will
disappear from the scrolling list. Press the
key.Once the last remaining input has been
tested, the following screen appears. Press the
key. 'Walk Test' will be display, press the
key.
Test Control?
To enter the Test Control press the
Enter the number of the inputs you wish to soak
test and press . The input number shows on
the scrolling list. Repeat for each input to be
tested. To remove an input from the list, enter its
number again. Press the
Test Days Left
Enter the number of days the soak test will last.
Press the key. Enter the number of days the
soak test will revert to in the event a soak input is
triggered during testing. Press the
Control' will be displayed, press
Page: 52
V i s u a l K e y p a d P r o g r a m m i n g P r o c e d u r e
E N G I N E E R T E S T S
keys, scroll to
key
key
key.
key. 'Test
key.
