Pyronix PCX-256 Programming Manual page 18

Number & Type
06 Immediate
Entry/Exit
07
(EE)
08 Access (A)
09 A (Part EE)
10 EE (Part A)
PTS
11
(Push to set)
12 Switcher
13 24 Hour
Sub Part
15
Control
16 Fault
Closure
17
Supervision
18 Shunt Input
19 Disarm Input
Keyswitch
20
Latched
Entry Shock
21
Input
22 Input Fail Fail
Keyswitch
23
Pulsed
NOTES: 'Part Arm' refers to any combination other than all available partitions
RINS868-6
Operation
Communicator: 'Tamper' signal
When armed: Audible Response: Full (differentiated)
Communicator: 'Tamper' and 'Unconfirmed' signals
Active when armed. Audible Response: Full
Communicator: 'Intruder' and 'Unconfirmed' signal
Active when armed – initiates entry timer if system not disarmed before
entry time expires: Audible Response: Full. Communicator: 'Intruder' signal
Active when armed, except during entry time. (Acts as an immediate
input if an entry/exit input hasn't been activated beforehand)
Audible Response: Full. Communicator: 'Intruder' and 'Unconfirmed' signal
(For use with part arms). When fully armed, it acts as an Access input as
above, when part armed; it acts as an Entry/Exit input.
(For use with part arms). When fully armed, it acts as an Entry/Exit input
as above, when part armed; it acts as an Access input.
Active during exit time to complete arming procedure
No audible or communicator response.
Note: May be used to act as 'doorbell' by use of 'chime' attribute.
Active at all times. No audible or communicator response
Triggers associated output or switches other equipment
When armed: Audible Response: Full. Communicator: 'Intruder' and
'Unconfirmed' signals
Programmable. Communicator: 'Day Alarm' signal
Input is allocated by system software and cannot be reprogrammed to a
different type, though relevant attributes may be adjusted.
Active when armed or disarmed. Audible Response: Graduated internal
Triggers 'Global Fault 1' output if the system is armed.
Triggers 'Global Fault 2' output if the system is armed or disarmed.
Active during arming procedure. No audible or communicator response
Prevents system being armed whilst active
Active at all times. No audible or communicator response
Accepts input from keyswitch (or equivalent) to shunt the inputs assigned
to it. Associated outputs are available. After 10 seconds the detectors in
the shunt list will be active. See page: 21
Active when armed. Accepts input from keyswitch (or equivalent) to
disarm the arm level assigned to it.
Accepts input from keyswitch (or equivalent) to arm/disarm the arm modes
assigned to it. Arming includes normal exit time, etc. Requires latching
switch action.
Active when system armed. Works in conjunction with EE input type for
detection of forced entry. See page 18 for details.
Active when fail. Will give a line fault alarm, and will signal telecom line
fault on expiry of line fault timer. Works in conjunction with CCTV input
Accepts input from keyswitch to arm/disarm the arm modes assigned to it.
Requires momentary action switch to toggle arm/disarm state.
PCX 256 PROGRAMMING MANUAL
When disarmed: Audible Response:
Page: 17
