PCX 256 PROGRAMMING MANUAL
Change Inputs
Using the and
INPUTS?'
Press the key
Input
Select the input number you wish to program as
the shunt input. Press the
Input Type
Select the shunt input type (type 18)
Shunt Inputs
If you would like to select the shunt inputs for the
selected input press the
Enter the inputs you would like in the shunt list,
after each one press the
selected will scroll on the display on the bottom
line. If the input you have selected doesn't
appear, make sure that input is programmed
correctly (Intruder, Tamper, 24Hr or Access).
Once they have all been entered press the
key, and press the
Partitions' will be displayed, follow the
instructions on page: 20 to program the rest.
Page: 22
V i s u a l K e y p a d P r o g r a m m i n g P r o c e d u r e
C H A N G E I N P U T S
S h u n t I n p u t s
keys, scroll to 'CHANGE
key.
key.
key. Each input
key again. 'Input
