PCX 256 PROGRAMMING MANUAL
Type
0059 Engineer Access
0060 Initialise Digi
0063 Test ATE/GSM
0064 Test ATS
0065 Zone Activity F1
0066 ATE Not Used
A repeating block of output types should be noted:
0202 Hold Up A
0203 Intruder A
0204 Final Arm A
0206 Confirmed A
0207 Tamper A
0208 Duress A
0209 HU Device A
0213 Secure Intr A
0214 Bell A
0216 Strobe A
0217 Omit At Rearm A
0218 Unconfirmed A
0219 Can Arm A
0220 Exit Starts A
Then this pattern repeats for each other partitions so that:
0221-0240 Partition / Arm Level B
0241-0260 Partition / Arm Level C
0261-0280 Partition / Arm Level D
0281-0300 Partition / Arm Level 0
0301-0320 Partition / Arm Level 1
0321-0340 Partition / Arm Level 2
0341-0360 Partition / Arm Level 3
1xxx Follow input xxx
i.e. add 1000 to the input number to select output required
NOTE: The following additional configurations are available, but are NOT programmable:
Partition Sounder
Page: 40
Defaults Active
When entering Engineer
Mode
At power up
Test signalling through PSTN
and GSM. Activates when a
test call is sent.
(used for specific GSMs)
Test signalling through PSTN
ATE 10
and GSM. Activates when a
DIGI 10
test call is sent.
Activates when there is no
activity on a zone with
respect to the "NAT timers"
in Change Timers.
As 0002 for Partition A / Arm Level A events only
As 0003 for Partition A / Arm Level A events only
As 0004 for Partition A / Arm Level A events only
As 0006 for Partition A / Arm Level A events only
As 0007 for Partition A / Arm Level A events only
As 0008 for Partition A / Arm Level A events only
As 0009 for Partition A / Arm Level A events only
As 0013 for Partition A / Arm Level A events only
As 0014 for Partition A / Arm Level A events only
As 0016 for Partition A / Arm Level A events only
As 0017 for Partition A / Arm Level A events only
As 0018 for Partition A / Arm Level A events only
As 0019 for Partition A / Arm Level A events only
As 0020 for Partition A / Arm Level A events only
When input is activated
The outputs of the RIX2 and PROX/INT are fixed as a
loudspeaker and can be used as a partitioning sounder,
partitions are selected in the 'Assign Keypads' section –
see page: 24
Restore
When leaving Engineer
Mode
Live for 45 seconds
When test completed
When test completed
When there is activity.
Makes the ATE pin 5V.
0361-0380 Partition / Arm Level 4
0381-0400 Partition / Arm Level 5
0401-0420 Partition / Arm Level 6
0421-0440 Partition / Arm Level 7
0441-0460 Partition / Arm Level 8
0461-0480 Partition / Arm Level 9
When input clears
RINS868-6
