Hardware ports, switches and LEDs

11.3 LEDs

The Gateway UNIGATE
the following significance:
LED (Ethernet) Power
LED Link/Act. 10 MB (only hard.-rev. A)
LED Link/Act. 100 MB (only hard.-rev. A) green
LED Full Duplex (from hard.-rev. B on)
LED 100 MB (from hard.-rev. B on)
LED Link/Act. (from hard.-rev. B on)
LED (Ethernet) State
LED Power
LED State
LEDs 1 / 2 / 4 / 8 (Error No. / Select ID)

11.3.1 LED "(Ethernet) Power"

This LED is connected directly to the Ethernet supply voltage.

11.3.2 LED "Link/Act. 10 MB" (rev. A only)

This LED is directly controlled by the Ethernet controller and it shines if the Gateway is located in
a working 10 MB-network (link pulses are being received) and it flickers when network data traffic
takes place.

11.3.3 LED "Link/Act. 100 MB" (rev. A only)

This LED is directly controlled by the Ethernet controller and it shines if the Gateway is located in
a working 100 MB-network (link pulses are being received) and it flickers when network data traf-
fic takes place.

11.3.4 LED "Full Duplex"

This LED flashes when the data transmission is full duplex.

11.3.5 LED "100 MB"

This LED displays, that the data communication occurs on the Ethernet LAN with 100 Mbit.

11.3.6 LED "Link/Act."

This LED is directly controlled by the Ethernet controller and it shines if the Gateway is located in
a working network (link pulses are being received) and it flickers when network data traffic takes
place.

11.3.7 LED "(Ethernet) State"

Lights green
Flashes green
Flashes green/red
Lights red

11.3.8 LED "Power"

This LED is connected directly to the (optionally also electrically isolated) supply voltage of the
serial interface (RS232/422/485).
30 UNIGATE
®
CL - Fast Ethernet features 10 LEDs or from hard.-rev. B 11 LEDs with
green
green
green
green
green
red/green
green
red/green
green
Connection established and active / a communication channel has been esta-
blished in the Gateway (see chapter 14.5)
No communication established
Gateway is waiting for Ethernet initialization
General network error
Fieldbus Gateway UNIGATE
®
Deutschmann Automation GmbH & Co. KG
Supply voltage Ethernet
Ethernet-link pulse found / network data traffic
Ethernet-link pulse found / network data traffic
Duplex transmission
100 MB-network
Ethernet-link pulses found / network data traffic
State of the interface Ethernet
Supply voltage serial interface Ethernet
User-defined / general Gateway error
User-defined / general Gateway error
