SSI-interface
//moveconst ( wTyp, 0x02); // i.e. Gray encoder, no clock stretch (High-Nibble=0)
moveconst ( wTyp, 0xF2); // i.e. Gray encoder, max clock stretch (High-Nibble=F)
Load the Script into the device. Open WINGATE and activate the device in the configuation
•
mode (see chapter 4.1, Configuration mode (config mode)) - an actuation message appears,
that looks in line with the following (example CL-PB):
Special Firmware (23) not loaded
RS-PBV1-CL (232/422/485) V7.31[30] (c)dA Switch=0x02FF Script(8k)="SSI"
Author="Deutschmann Automation" Version="V 1.0" Date=20.03.2008 SN=47110002 ID=2
Konfigmode...
The note "Special Firmware (23) not loaded" means that the firmware-extension is not yet
loaded. The extension is loaded through Extras -> Firmware Script Extension. Select the file
"Cust0023 (Cmd 23 + 24 for SSI).hex" and choose "write extension".
Re-start the device
•
note any more.
Bring the device into the data exchange mode (see chapter 4.3, Data exchange mode)
•
DONE!
6.2

Hardware-wiring

The clock wires of the SSI-interface are placed onto the Tx-wires of the RS422-interface and the
data wires onto the Rx-wires at the UNIGATE
X1 (3pin + 4pin screw-plug-connector):
Pin no. Name
1 Rx 232
2 Tx 232
3 AP-GND
4 Rx 422+
5 Rx 422-
6 Tx 422+
7 Tx 422-
16 UNIGATE
→
now only the device's actual actuation message appears and not the
®
Function at SSI
n. c.
n. c.
n. c.
SSI DAT+
SSI DAT-
SSI CLK+
SSI CLK-
