A.2 Technical data, MSD Servo Drive
A.2.1
G392-004A to G392-016, air cooling
Designation
Technical data
Output, motor side
1)
Voltage
4)
Rated current, effective (l
)
4 A
N
Peak current
See A.1.1
Rotating field frequency
Switching frequency of the power
stage
Input, mains side
1 x 230 V
Mains voltage
±10 %
Device connected load
1)
2.2 kVA
(with mains choke)
Current
1)
(with mains choke)
9.5 A
2)
Asymmetry of mains voltage
-
Frequency
Power dissipation at I
1)
85 W
N
1)
Data referred to mains voltage 3 x 400 V
(for G392-004A: 1 x 230 Veff) and switching frequency of power stage 8 kHz
eff
2)
Without mains choke
3)
Connection of an ext. braking resistor to devices with int. braking resistor not permitted (model G392-xxx-xxx-xx2/xx4)!
4)
When designing the drive, it is to be taken into account that the maximum output voltage reduces as a function of the active power.
Table A.9 Technical data, G392-004A to G392-016, air cooling
3-phase U
Mains
4 A
6 A
8 A
12 A
16 A
See A.1.2
0 ... 400 Hz
4, 8, 12, 16 kHz
(3 x 230 V/ 3 x 400 V/ 3 x 460 V/ 3 x 480 V) ±10 %
2.9 kVA
4.4 kVA
6 kVA
9.1 kVA
12 kVA
4.2 A
6.4 A
8.7 A
13.1 A
17.3 A
±3 % maximum
50/60 Hz ±10 %
96 W
122 W
175 W
240 W
330 W
MSD Single-Axis System Operation Manual AC-AC Servo Drive
Designation
Technical data
DC link
Capacitance
1740 µF
Brake chopper switch-on threshold
1)
390 V DC
Minimum ohmic resistance of an
externally installed braking resistor
3)
Brake chopper peak power
2.1 kW
with external braking resistor
1)
Optional:
Internal braking resistor
Brake chopper peak power
See "Table 4.21 Data on the integrated braking resistor (model G392-xxx-xxx-
with internal braking resistor
1)
Data referred to mains voltage 3 x 400 V
(for G392-004A: 1 x 230 Veff) and switching frequency of power stage 8 kHz
eff
2)
Without mains choke
3)
Connection of an ext. braking resistor to devices with int. braking resistor not permitted (model G392-xxx-xxx-xx2/xx4)!
4)
When designing the drive, it is to be taken into account that the maximum output voltage reduces as a function of the active power.
Table A.9 Technical data, G392-004A to G392-016, air cooling
NOTE:
You will find more information on the brake chopper switch-on threshold in
chapter "4.6 Connection of PE conductor"
400 µF
725 µF
1230 µF
650 V DC
72 Ω
39 Ω
5.9 kW
11 kW
21 kW
PTC (175 Ω)
90 Ω
xx2/xx4 and G395-xxx-xxx-xx2/xx4)"
72
20 Ω
