Technical data MSD Single-Axis Servo
A.2
Drive Compact
G394-030, G394-059 and G394-080
Designation
G394-030
Technical data
Output, motor side
Voltage
Rated current effective (l ) 3.0 A
n
Peak current (2 x I / 3 x I )
N N
Rotating field frequenc
Switching frequency of power stage
Input, mains side
Mains voltage
Device connected load
1.3 kVA
(with mains choke)
1 x 230 V AC 5.4 A
Current consumption
(with mains choke)
3 x 230 V AC
3.3 A
Asymmetry of mains voltage
Permissible mains frequency
1) Data referred to output voltage 230 V AC and switching frequency 8 kHz,
2) For rated current refer to table A.1 or table A.2 !
3) On design with integrated braking resistor (G394-xxx-xxx-xx2/xx4). Connection of an external braking resistor is not permitted.
4) Braking resistor always integrated. Connection of an external resistor is permissible.
Table A.6 Technical data G394-030, G394-059 and G394-080
G394-059 G394-080
3 phase U
Mains
1) 2) 5.9 A 1) 2) 8.0 A 1) 2)
see tables A.1 and A.2
0 ... 400 Hz
4, 8, 16 kHz
(1 x 230 V AC / 3 x 230 V AC) -20 %/+15 %
2.6 kVA 3.5 kVA
1) 1) 1)
10.6 A 14.4 A
6.5 A 8.8 A
±3 % maximum
50/60 Hz ±10 %
MSD Single-Axis Servo Drive Compact Operation Manual
Designation
G394-030
Technical data
Power loss at I 75 W
N
DC link
Brake chopper switch-on threshold
DC link capacitance 880 µF
Minimum ohmic resistance of an exter-
72 Ω
nally installed braking resistor
Brake chopper continuous power
with external braking resistor
Peak brake chopper with external
braking resistor
Internal braking resistor 550 Ω (PTC)
Brake chopper continuous power
0 W
with internal braking resistor
Peak brake chopper with internal
400 W
braking resistor
1) Data referred to output voltage 230 V AC and switching frequency 8 kHz,
2) For rated current refer to table A.1 or table A.2 !
3) On design with integrated braking resistor (G394-xxx-xxx-xx2/xx4). Connection of an external braking resistor is not permitted.
4) Braking resistor always integrated. Connection of an external resistor is permissible.
Table A.6 Technical data G394-030, G394-059 and G394-080
NOTE:
For more information on the brake chopper switch-on threshold also refer to
chapter "4.15 Brake chopper connection".
62
G394-059 G394-080
1) 150 W 1) 200 W 1)
390 V DC
1)
1760 µF
1320 µF
4) 72 Ω 3) 72 Ω 3)
2.1 kW
2.1 kW
100 Ω 90 Ω
4) 3 3)
Dependent on the effective utilisation of the servo
drive in the specific application see chapter 4.15.2
1500 W 1700 W
