Moog MSD Operation Manual page 70

moog
ID no.: CA65642-001 06/2018
Power stage
Ambient
switching Rated
temperature
Servo drive frequency current
[kHz] [°C]/°F[
4
8
G395-110 +45
(Size 6) (+113)
12
16
4
8
G395-143 +45
(Size 6) (+113)
12
16
4
8
G395-170 +45
(Size 6A) (+113)
12
16
4
8
G395-210 +45
(Size 6A) (+113)
12
16
All data apply for a motor cable length ≤10 m (32.80 ft).
1) Shutdown as per I²t characteristic
2) Permissible peak current at 70 % initial load
Table A.7 Rated and peak current, Size 6 and Size 6A (liquid cooling)
At mains voltage 400 V
Peak current [Aeff]
2)
During
Rated
At rotating field inter-
current
frequency increas- mittent
ing linearly opera-
tion
Up to 5
[Aeff] 0 Hz >5 Hz [Aeff]
Hz
110 206 220 102
110 166 187 102
110 133 165 102
90 106 135 83
143 232 286 132
143 192 215 132
114 153 171 105
91 123 137 84
170 232 340 157
170 192 255 157
136 153 204 126
109 123 164 101
210 232 340 194
210 192 255 194
168 153 204 155
134 123 164 124
MSD Single-Axis System Operation Manual AC-AC Servo Drive
At mains voltage 460 V At mains voltage 480 V
Peak current [Aeff]
2)
During
Rated
At rotating field inter-
current
frequency increas- mittent frequency increas-
ing linearly opera-
tion
Up to 5
0 Hz >5 Hz [Aeff]
Hz
191 204 99
154 173 99
123 153 99
99 125 81
214 264 129
177 198 129
142 158 103
114 126 82
214 314 153
177 236 153
142 189 122
114 152 98
214 314 189
177 236 189
142 189 151
114 152 121
Peak current [Aeff]
2)
During
Overload
At rotating field inter-
factor ≥5 Hz
mittent
ing linearly opera-
tion
Up to 5
0 Hz >5 Hz [%]
Hz
186 198 200
150 168 170
120 149 150
96 122 150
208 258 200
172 194 150
138 155 150
111 123 150
208 306 200
172 230 150
138 183 150
111 147 150
208 306 160
172 230 120
138 183 120
111 147 120
70
For time
1)
[s]
30
30
10
10
