Dual Input; Breaker Or Switch (Q4) - Delta Modulon DPH series User Manual

UPS-1.1 MEASUREMENT
Power Flow
POWER FLOW
Maintenance
Power Flow
Bypass
Bypass
Summary
Mains
System Status
90 %
5 mins
(Figure 6-65 : Bypass Mode Screen_ Administrator Login)
5 Click SETUP Mode Setting
the UPS will run in bypass mode to let the bypass AC source supply power to the
output.
UPS-1.1 MEASUREMENT
MODE SETTING
On-Line
6
Single Input:
Switch OFF the UPS's bypass switch (Q0), Delta or non-Delta external maintenance
bypass cabinet's input breaker or switch (Q1) and output breaker or switch (Q4).

Dual Input:

Switch OFF the UPS's bypass switch (Q0), Delta or non-Delta external maintenance
bypass cabinet's input breaker or switch (Q1), bypass breaker or switch (Q2) and output

breaker or switch (Q4).

Administrator Login
SETUP MAINTENANCE
Administrator
On-Line. If the bypass voltage is in the normal range,
SETUP MAINTENANCE
Mode Setting Administrator
Select to change system mode
Green ECO
(Figure 6-66: Select On-Line Mode)
6-47
LOG IN EVENT LOG
Load
30 %
LOG IN EVENT LOG
Energy Frequency
Recycle Conversion
6 UPS Operation
