Delta Modulon DPH series User Manual page 125

7 Press the ON/ OFF button (
if you want to power on the UPS's inverter. Please select 'YES'.
UPS-1.1 MEASUREMENT
Power Flow
8 After selection of 'YES' to start up the UPS's inverter, each power module will start up
and perform self-inspection. At the same time, the system begins synchronization with
the bypass AC source. After the self-inspection is completed, the UPS will automatically
transfer to run in online mode, the tri-color LED indicator will illuminate green and the
following screen will appear. For the tri-color LED indicator location, please refer to
Figure 2-11.
UPS-1.1 MEASUREMENT
Power Flow
POWER FLOW
Maintenance
Power Flow
Bypass
Bypass
Summary
Mains
System Status
90 %
5 mins
) once and the following screen will pop up to ask you
SETUP MAINTENANCE
POWER ON ?
Yes
(Figure 6-4: Power on Reminder Screen)
SETUP MAINTENANCE
(Figure 6-5 : Online Mode Screen)
6-7
LOG IN EVENT LOG
User
No
LOG IN EVENT LOG
User
Load
30 %
6 UPS Operation
10:15
May 25,2018
Standby
10:15
May 25,2018
On-Line
